| 12″ Mitsubishi Touch screen HMI | GT2715-XTBA GT2715-XTBD | GT2712-STBA GT2712-STBD | GT2712-STWA GT2712-STWD | GT2710-STBA GT2710-STBD | GT2710-VTBA GT2710-VTBD | GT2710-VTWA GT2710-VTWD | GT2708-STBA GT2708-STBD | GT2708-VTBA GT2708-VTBD | GT2705-VTBD |
| Type | TFT color LCD | ||||||||
| Screen Size | 15″ | 12.1″ | 10.4″ | 8.4″ | 5.7″ | ||||
| Resolution (Dots) | 1024 x 768 XGA | 800 x 600 SVGA | 640 x 480 VGA | 800 x 600 SVGA | 640 x 480 VGA | ||||
| Display Size (W x H) mm | 304.1 x 228.1 | 246.0 x 184.5 | 211.2 x 158.4 | 170.9 x 128.2 | 115.2 x 86.4 | ||||
|
Number of Characters |
16-dot standard font: 64 chars. x 48 lines (2-byte) 12-dot standard font: 85 chars. x 64 lines (2-byte) |
16-dot standard font: 50 chars. x 37 lines (2-byte) 12-dot standard font: 66 chars. x 50 lines (2-byte) |
16-dot standard font: 40 chars. x 30 lines (2-byte) 12-dot standard font: 53 chars. x 40 lines (2-byte) |
16-dot standard font: 50 chars. x 37 lines (2-byte) 12-dot standard font: 66 chars.
x 50 lines (2-byte) |
16-dot standard font: 40 chars. x 30 lines (2-byte) 12-dot standard font: 53 chars. x 40 lines (2-byte) |
||||
| Display Colors | 65536 colors | ||||||||
| Intensity Adjustment | 32-level adjustment | ||||||||
| Backlight
Type |
LED (not replaceable) | ||||||||
| Life | Approx. 60000 hours or more (Time for display intensity reaches 50% at ambient temperature of 25°C) (*4) | ||||||||
|
Touch Panel (*3) Type |
Analog resistive film | ||||||||
| Key Size (Dots) | Minimum 2 x 2 dots (per key) (*7) | ||||||||
| Simultaneous Press | Maximum 2 points | ||||||||
| Life | 1 million times or more (operating force 0.98N or less) | ||||||||
| Panel Color | Black | White | Black | White | Black | ||||
| Human Sensor
Detection Distance (m) |
1m | – | |||||||
| Detection Temperature | Temperature difference between human body and ambient air: 4°C or higher | – | |||||||
|
Memory
User Memory Capacity |
Memory for storage (ROM): 57MB, Memory for operation (RAM): 128MB |
Memory for storage (ROM): 32MB, Memory for operation (RAM): 80MB | |||||||
| Life (No. of Writings) | 100000 times | ||||||||
| Internal Clock Accuracy | ±90 sec/month (ambient temperature 25°C) | ||||||||
| Battery Type | GT11-50BAT lithium battery | ||||||||
| Life | Approx. 5 years (ambient temperature 25°C) | ||||||||
| Built-in Interface
RS-232 |
1ch Transmission speed: 115200/57600/38400/19200/9600/4800bps Connector shape: D-sub 9-pin (male) | ||||||||
| RS-422/485 | 1ch Transmission speed: 115200/57600/38400/19200/9600/4800bps Connector shape: D-sub 9-pin (female) | ||||||||
| Ethernet | 1ch Data transfer method: 10BASE-T/100BASE-TX Connector shape: RJ-45 (modular jack) | ||||||||
| USB (Host) | 2ch (front face/rear face) | 1ch (rear face) | 2ch (front face/rear face) | 1ch (rear face) | 2ch (front face/rear face) | ||||
| Maximum transfer speed: High-Speed 480Mbps Connector shape: USB-A | |||||||||
| USB (Device) | 1ch (front face) | 1ch (rear face) | 1ch (front face) | 1ch (rear face) | 1ch (front face) | ||||
| Maximum transfer speed: High-Speed 480Mbps Connector shape: USB Mini-B | |||||||||
| SD Card | 1ch SDHC compliant (maximum 32GB) | ||||||||
| Extension Interface (*6) | For communication unit/option unit mounting | ||||||||
| Auxiliary Extension I/F | For option unit mounting | – | |||||||
| Side Interface | For communication unit mounting | ||||||||
| Buzzer Output | Single tone (tone, tone length adjustable) | ||||||||
| Power LED | Emission color: 2 colors (blue, orange) | ||||||||
| Protective Construction | Front: IP67F (*5,*8) In control panel: IP2X | ||||||||
| External Dimensions (W x H x D) mm | 397 x 300 x 60 | 316 x 246 x 52 | 303 x 218 x 52 | 241 x 194 x 52 | 167 x 139 x 60 | ||||
| Panel Cutout (W x H) mm | 383.5 x 282.5 | 302 x 228 | 289 x 200 | 227 x 176 | 153 x 121 | ||||
| Weight (kg)
Excludes Mounting Brackets |
4.5 | 2.4 | 2.1 | 1.5 | 1.0 | ||||
|
Applicable Software Package |
GT Works3 Version1.112S or later |
GT Works3 Version1.100E or later |
GT Works3 Version1.130L or later | ||||||
