12″ Mitsubishi Touch screen HMI | GT2715-XTBA GT2715-XTBD | GT2712-STBA GT2712-STBD | GT2712-STWA GT2712-STWD | GT2710-STBA GT2710-STBD | GT2710-VTBA GT2710-VTBD | GT2710-VTWA GT2710-VTWD | GT2708-STBA GT2708-STBD | GT2708-VTBA GT2708-VTBD | GT2705-VTBD |
Type | TFT color LCD | ||||||||
Screen Size | 15″ | 12.1″ | 10.4″ | 8.4″ | 5.7″ | ||||
Resolution (Dots) | 1024 x 768 XGA | 800 x 600 SVGA | 640 x 480 VGA | 800 x 600 SVGA | 640 x 480 VGA | ||||
Display Size (W x H) mm | 304.1 x 228.1 | 246.0 x 184.5 | 211.2 x 158.4 | 170.9 x 128.2 | 115.2 x 86.4 | ||||
Number of Characters |
16-dot standard font: 64 chars. x 48 lines (2-byte) 12-dot standard font: 85 chars. x 64 lines (2-byte) |
16-dot standard font: 50 chars. x 37 lines (2-byte) 12-dot standard font: 66 chars. x 50 lines (2-byte) |
16-dot standard font: 40 chars. x 30 lines (2-byte) 12-dot standard font: 53 chars. x 40 lines (2-byte) |
16-dot standard font: 50 chars. x 37 lines (2-byte) 12-dot standard font: 66 chars.x 50 lines
(2-byte) |
16-dot standard font: 40 chars. x 30 lines (2-byte) 12-dot standard font: 53 chars. x 40 lines (2-byte) |
||||
Display Colors | 65536 colors | ||||||||
Intensity Adjustment | 32-level adjustment | ||||||||
BacklightType | LED (not replaceable) | ||||||||
Life | Approx. 60000 hours or more (Time for display intensity reaches 50% at ambient temperature of 25°C) (*4) | ||||||||
Touch Panel (*3)
Type |
Analog resistive film | ||||||||
Key Size (Dots) | Minimum 2 x 2 dots (per key) (*7) | ||||||||
Simultaneous Press | Maximum 2 points | ||||||||
Life | 1 million times or more (operating force 0.98N or less) | ||||||||
Panel Color | Black | White | Black | White | Black | ||||
Human SensorDetection Distance (m) | 1m | – | |||||||
Detection Temperature | Temperature difference between human body and ambient air: 4°C or higher | – | |||||||
Memory
User Memory Capacity |
Memory for storage (ROM): 57MB, Memory for operation (RAM): 128MB | Memory for storage (ROM): 32MB, Memory for operation (RAM): 80MB | |||||||
Life (No. of Writings) | 100000 times | ||||||||
Internal Clock Accuracy | ±90 sec/month (ambient temperature 25°C) | ||||||||
Battery Type | GT11-50BAT lithium battery | ||||||||
Life | Approx. 5 years (ambient temperature 25°C) | ||||||||
Built-in InterfaceRS-232 | 1ch Transmission speed: 115200/57600/38400/19200/9600/4800bps Connector shape: D-sub 9-pin (male) | ||||||||
RS-422/485 | 1ch Transmission speed: 115200/57600/38400/19200/9600/4800bps Connector shape: D-sub 9-pin (female) | ||||||||
Ethernet | 1ch Data transfer method: 10BASE-T/100BASE-TX Connector shape: RJ-45 (modular jack) | ||||||||
USB (Host) | 2ch (front face/rear face) | 1ch (rear face) | 2ch (front face/rear face) | 1ch (rear face) | 2ch (front face/rear face) | ||||
Maximum transfer speed: High-Speed 480Mbps Connector shape: USB-A | |||||||||
USB (Device) | 1ch (front face) | 1ch (rear face) | 1ch (front face) | 1ch (rear face) | 1ch (front face) | ||||
Maximum transfer speed: High-Speed 480Mbps Connector shape: USB Mini-B | |||||||||
SD Card | 1ch SDHC compliant (maximum 32GB) | ||||||||
Extension Interface (*6) | For communication unit/option unit mounting | ||||||||
Auxiliary Extension I/F | For option unit mounting | – | |||||||
Side Interface | For communication unit mounting | ||||||||
Buzzer Output | Single tone (tone, tone length adjustable) | ||||||||
Power LED | Emission color: 2 colors (blue, orange) | ||||||||
Protective Construction | Front: IP67F (*5,*8) In control panel: IP2X | ||||||||
External Dimensions (W x H x D) mm | 397 x 300 x 60 | 316 x 246 x 52 | 303 x 218 x 52 | 241 x 194 x 52 | 167 x 139 x 60 | ||||
Panel Cutout (W x H) mm | 383.5 x 282.5 | 302 x 228 | 289 x 200 | 227 x 176 | 153 x 121 | ||||
Weight (kg)Excludes Mounting Brackets | 4.5 | 2.4 | 2.1 | 1.5 | 1.0 | ||||
Applicable Software Package | GT Works3 Version1.112S or later | GT Works3 Version1.100E or later | GT Works3 Version1.130L or later |
