General information | 22 inch Siemens SIMATIC HMI TP2200 Comfort Pro Panel 6AV2124-0XC24-0AX0 | ||
Product type designation | TP2200 Comfort PRO | ||
Design of display | TFT | ||
Screen diagonal | 21.5 in | ||
Display width | 475,2 mm | ||
Display height | 267.3 mm | ||
Number of colors | 16 777 216 | ||
● Horizontal image resolution● Vertical image resolution | 1920 Pixel1080 Pixel | ||
● MTBF backlighting (at 25 °C)● Backlight dimmable | 50 000 hYes; 0-100 % | ||
● Function keys— Number of function keys | 0 | ||
● Design as touch screen | Yes; Projective-capacitive | ||
● Direct keys (touch buttons as S7 input I/O) | 40 | ||
Mounting | Support arm | ||
Mounting position | vertical | ||
Mounting in portrait format possible | No | ||
maximum permissible angle of inclination without external ventilation | 35° | ||
Type of supply voltage | DC | ||
Rated value (DC) | 24 V | ||
permissible range, lower limit (DC) | 19.2 V | ||
permissible range, upper limit (DC) | 28.8 V | ||
Current consumption (rated value) | 1.5 A | ||
Starting current inrush I²t | 0.5 A²·s | ||
Flash | Yes | ||
RAM | Yes | ||
Memory available for user data | 24 Mbyte |
