4.7" Mitsubishi HMI Touch screen GT1045-QSBD GT1040-QBBD

Series#: Mitsubishi HMI

Product Details

  • 4.7″ [320 240 dots], STN monochrome liquid crystal, monochrome (blue and white), 16 scales,
  • built-in battery 24VDC,
  • PLC connection interface: RS-422, RS-232
  • 4.7″ Mitsubishi HMI Touch screen GT1045-QSBD GT1040-QBBD
  • We are First Class mitsubishi plc dealer and mitsubishi plc distributor in China.
  • We can Supply mitsubishi electric automation parts,such as Mitsubishi PLC,Mitsubishi Servo Motor,Mitsubishi HMI,Mitsubishi VFD and So on,
  • 100% Original and new,In stock by Mitsubishi PLC
  • Delivery time: Ready in stock and 1 days for ship out
  • MOQ: 1pcs
Qty:

Specification

Item Specifications
Mitsubishi HMI Touch screen GT1045 GT1045-QSBD GT1040-QBBD
Display section*1

Type

STN color liquid crystal STN monochrome (white/blue) liquid crystal
Screen size 4.7″
Resolution 320 240 dots (Horizontal format)
Display size W96(3.77) H72(2.83) [mm](inch) (Horizontal format)
Display character 16-dot standard font: 40 characters 15 lines (Horizontal format) 12-dot standard font: 53 characters 20 lines (Horizontal format)
Display color 256 colors Monochrome (white/blue), 16 scales


Display angle

Left/Right: 50 degrees, Top: 40 degrees, Bottom: 70 degrees (Horizontal format) Left/Right: 45 degrees, Top: 20 degrees, Bottom: 40 degrees (Horizontal format)
Contrast adjustment 16-level adjustment
Intensity of LCD only 150 [cd/m2] 300 [cd/m2]


Life

Approx. 50,000h. (Time for display intensity to become 1/5 at operating ambient temperature of 25)
Backlight LED Backlight off/screen saving time can be set.
Touch panel

Number of touch keys

Maximum 50 keys/screen (Matrix resistive film touch panel)
Key size Minimum 16 16 dots (per key)
Number of points touched simultaneously Maximum of 2 points
Life 1 million times or more (operating force 0.98N max.)
Memory

C drive*2

Flash memory (Internal), for storing project data (3Mbytes or less), OS
Life (Number of write times) 100,000 times


D drive

SRAM (Internal), for storing alarm history, recipe data and time action setting value
Battery GT11-50BAT lithium battery
Backup target Clock data, alarm history, recipe data and time action setting value
Life Approx. 5 years (Operating ambient temperature of 25)




Built-in interface



RS-422

RS-422/485 1ch

Transmission speed :115,200/57,600/38,400/19,200/9,600/4,800bps Connector shape :D-sub 9 pins (Female)

Application :PLC communication

Terminating resistor*4  :Open/110   /330     (Switched by terminating resistor selector switch)







RS-232

RS-232 1ch

Transmission speed :115,200/57,600/38,400/19,200/9,600/4,800bps Connector shape :D-sub 9 pins (Male)

Application :PLC communication, bar code reader connection, PC

communication (Project data upload/download, OS installation, transparent function)





USB

USB (Full Speed 12Mbps) 1ch Connector shape :Mini-B

Application :PC communication (Project data upload/download, OS installation, transparent function)

Memory board For connecting memory board (GT10-50FMB), 1ch
Buzzer output (a buzzer that sounds when touch keys are pressed) Single tone (LONG/SHORT/OFF adjustable)
Environmental protective structure*3 Equivalent to IP67 (JEM1030) (front section) (Horizontal format)
External dimensions W139(5.47) H112(4.4) D41(1.61) (Excluding mounting fixtures) [mm](inch) (Horizontal format)
