4 inch Siemens SIMATIC HMI KP400 Comfort Panel Touch Screen 6AV2124-1DC01-0AX0

Series#: Siemens HMI

Product Details

  • 4 inch Siemens SIMATIC HMI KP400 Comfort Panel Touch Screen 6AV2124-1DC01-0AX0
  • SIMATIC HMI KP400 Comfort, Comfort Panel, key operation
  • 4″ widescreen TFT display, 16 million colors
  • PROFINET interface, MPI/PROFIBUS DP interface
  • 4 MB configuration memory
  • Windows CE 6.0, (Microsoft Support included Security updates discontinued)
  • configurable from WinCC Comfort V11
Qty:

Specification

General information 4 inch Siemens SIMATIC HMI KP400 Comfort Panel Touch Screen 6AV2124-1DC01-0AX0
Product type designation KP400 Comfort
Design of display TFT
Screen diagonal 4.3 in
Display width 95 mm
Display height 53.8 mm
Number of colors 16 777 216
● Horizontal image resolution

● Vertical image resolution

480 Pixel

272 Pixel

● MTBF backlighting (at 25 °C)

● Backlight dimmable

80 000 h

Yes; 0-100 %

● Function keys

— Number of function keys



8

— Number of function keys with LEDs

● Keys with LED

● System keys

● Numeric keyboard

● alphanumeric keyboard

8

Yes Yes Yes Yes;











similar











to











mobile











phone

● Design as touch screen No
● DP direct LEDs (LEDs as S7 output I/O)
— F1…Fx 8
● Direct keys (keys as S7 input I/O)
— F1…Fx 8
● Direct keys (touch buttons as S7 input I/O) 0
Mounting position vertical
Mounting in portrait format possible No
Mounting in landscape format possible Yes
maximum permissible angle of inclination without external ventilation 35°
Type of supply voltage DC
Rated value (DC) 24 V
permissible range, lower limit (DC) 19.2 V
permissible range, upper limit (DC) 28.8 V
Current consumption (rated value) 0.13 A
Starting current inrush I²t 0.5 A²·s
Processor type ARM
