| HITECH (Beijer) PWS operator Panels HMI Touch screen |
PWS6620S-P |
PWS6620S-N |
PWS6620T-P |
PWS6620T-N |
| LCD Type |
Mono STN LCD |
Color TFT LCD |
| Screen size |
5.7” (diagonal) |
| Display resolution |
320×240 |
| Brightness (cd/m2) |
160 |
400 |
|
|
|
| Contrast adjustment |
Via touch panel |
— |
|
|
|
| Display colors |
16 shades of blue |
64K colors |
| Back light type |
CCFL |
LED |
| CPU |
32-bit RISC |
| Back light life |
50,000 hours |
| Operation Status LED |
PWR, COM1, COM 2, Ethernet LEDs |
|
|
| Touch screen |
Analog |
|
|
| Touch screen |
|
| (number of times) |
> 1,000,000 |
|
|
|
|
| Keypad |
1 Menu key and 5 user-defined function keys (F1—F5) |
| Application Flash ROM |
4MB |
| RAM |
16MB |
| Data/Recipe |
512KB |
| RTC |
|
| (w/rechargeable lithium battery) |
Yes |
|
|
| Data storage (CF card) |
Yes |
|
|
| COM1 |
9-pin female (RS232/RS485) |
|
|
| COM2 |
25-pin female (RS232/RS422/RS485) |
|
|
| COM3 |
— |
| USB Host |
1 |
| USB Device |
1 |
|
|
| Multi-functional port |
— |
|
|
| Ethernet |
— |
Yes |
— |
Yes |
|
|
| External dimensions (mm) |
195.0 (W) x 145.0 (H) x 59.1 (D) |
| Cut-out dimensions (mm) |
185.8 x 135.8 |
| Supply voltage |
24V DC ±15 %, < 20W |
| Front protection |
IP65 |
| Certification |
CE,UL,FCC |
| Weight (kg) |
0.81 |
