| Specifications |
7.0″ Proface Touch screen HMI PFXGP4402WADW |
| Part Number |
PFXGP4402WADW |
|
| Display Size |
7.0″ |
|
| Display Type |
TFT Color LCD |
| Resolution |
800 x 480 pixels (WVGA) |
| Display Colors |
65,536 Colors |
| Backlight |
LED |
| Application Memory |
FLASH EPROM 32 MB *1 |
| Data Backup |
FLASH EPROM 128 KB |
| Serial (COM1) |
RS-232C (D-Sub 9-pin, plug) |
| Serial (COM2) |
RS-422 / 485 (D-Sub 9-pin, plug) |
| Ethernet (LAN) |
10 / 100 Mbps (RJ-45 Modular Jack) |
| USB (Type-A) |
USB 2.0 x 1 (Type A) |
| USB (mini-B) |
USB 2.0 x 1 (mini-B) |
| Rated Input Voltage |
24 Vdc |
| Power Consumption |
9.2 W |
|
| Ambient Oper. Temp. |
0 to 50 °C [32 to 122 °F] |
| Weight Approx. |
0.56 kg [1.235 lb] |
|
| Structure |
Front Panel: (IEC60529), Enclosure type 4 indoor use only (UL 50) with screw installation fasteners, Rear Panel: IP 20 (IEC 60529) |
| External Dimensions |
W207 x H152.4 x D38.2 mm [W8.15 x H6.00 x D1.50 in.] |
|
