| General information | 7 inch Siemens SIMATIC HMI TP700 Comfort Panel Touch Screen 6AV2124-0GC01-0AX0 | ||||
| Product type designation | TP700 Comfort | ||||
| Design of display | TFT | ||||
| Screen diagonal | 7 in | ||||
| Display width | 152.4 mm | ||||
| Display height | 91.4 mm | ||||
| Number of colors | 16 777 216 | ||||
| ● Horizontal image resolution
● Vertical image resolution |
800 Pixel
480 Pixel |
||||
| ● MTBF backlighting (at 25 °C)
● Backlight dimmable |
80 000 h
Yes; 0-100 % |
||||
| ● Function keys
— Number of function keys |
0 |
||||
| — Number of function keys with LEDs
● Keys with LED ● System keys ● Numeric keyboard ● alphanumeric keyboard |
0
No No Yes; Yes; |
Onscreen Onscreen |
keyboard keyboard |
||
| ● Design as touch screen | Yes | ||||
| ● DP direct LEDs (LEDs as S7 output I/O) | |||||
| — F1…Fx | 0 | ||||
| ● Direct keys (keys as S7 input I/O) | |||||
| — F1…Fx | 0 | ||||
| ● Direct keys (touch buttons as S7 input I/O) | 32 | ||||
| Mounting position | vertical | ||||
| Mounting in portrait format possible | Yes | ||||
| Mounting in landscape format possible | Yes | ||||
| maximum permissible angle of inclination without external ventilation | 35° | ||||
| Type of supply voltage | DC | ||||
| Rated value (DC) | 24 V | ||||
| permissible range, lower limit (DC) | 19.2 V | ||||
| permissible range, upper limit (DC) | 28.8 V | ||||
| Current consumption (rated value) | 0.5 A | ||||
| Starting current inrush I²t | 0.5 A²·s | ||||
| Active power input, typ. | 12 W | ||||
| Flash | Yes | ||||
| RAM | Yes | ||||
| Memory available for user data | 12 Mbyte | ||||
