| Model: ASDA-B2 Series |
100W |
200W |
400W |
750W |
1kW |
1.5kW |
2kW |
3kW |
| 01 |
02 |
04 |
07 |
10 |
15 |
20 |
30 |
| PowerSupply |
Phase / Voltage |
Three-phase: 170 ~ 255VAC, 50／60Hz ±5%Single-phase: 200 ~ 255VAC, 50／60Hz ±5% |
Three-phase: 170 ~ 255VAC,50／60Hz ±5% |
| Continuous Output Current |
0.9Arms |
1.55Arms |
2.6Arms |
5.1Arms |
7.3Arms |
8.3Arms |
13.4Arms |
19.4Arms |
| Cooling System |
Natural Air Circulation |
Fan Cooling |
| Encoder Resolution / Feedback Resolution |
17-bit (160000 p/rev) |
| Control of Main Circuit |
SVPWM Control |
| Tuning Modes |
Auto / Manual |
| Dynamic Brake |
– |
Built-in |
| Position Control Mode |
Max. Input Pulse Frequency |
Line driver: Max. 500Kpps (low speed)/ Max.4Mpps(high speed) Open collector: Max. 200Kpps |
| Pulse Type |
Pulse + Direction, A phase + B phase, CCW pulse + CW pulse |
| Command Source |
External pulse train / Internal parameters |
| Smoothing Strategy |
Low-pass filter |
| Electronic Gear |
Electronic gear N/M multiple N: 1 ~ (226-1)/M:1 ~ (231-1)1/50 < N/M < 25600 |
| Torque Limit Operation |
Set by parameters |
| Feed Forward Compensation |
Set by parameters |
| Speed Control Mode |
Analog Input Command |
Voltage Range |
0 ~ ±10 VDC |
| InputResistance |
10KW |
| Time Constant |
2.2 us |
| Speed Control Range*1 |
1:5000 |
| Command Source |
External analog signal / Internal parameters |
| Smoothing Strategy |
Low-pass and S-curve filter |
| Torque Limit Operation |
Set by parameters or via Analog input |
| ResponsivenessCharacteristic |
Maximum 550Hz |
| Speed Fluctuation Rate*2 (at rated speed) |
0.01% or less at load fluctuation 0 to 100% |
| 0.01% or less at power fluctuation ±10% |
| 0.01% or less at ambient temperature fluctuation 0oC to 50oC |
