MODEL | DOP-B03S211 | DOP-B03E211 | |
LCD MODULE
Display Type |
4.3″ TFT LCD (65536 colors ) | ||
Resolution | 480 x 272 pixels | ||
Backlight | LED Back Light (less than 20,000 hours half-life at 25oC) (Note 1) | ||
Display Size | 95.04 x 53.856mm | ||
Operation System | Delta Real Time OS | ||
MCU | 32-bit RISC Micro-controller | ||
NOR Flash ROM | Flash ROM 128 MB
(OS System: 30MB / Backup: 16MB / User Application: 82MB) |
||
SDRAM | 64Mbytes | ||
Backup Memory | 32Kbytes | ||
Buzzer |
Multi-Tone Frequency (2K ~ 4K Hz) / 85dB |
||
USB | 1 USB Slave Ver 2.0
1 USB Host Ver 1.1 |
||
Serial COM Port
COM1 |
RS-232(supports hardware flow control) / RS-485 | ||
COM2 | RS-422/RS-485 | ||
Ethernet Interface | N/A | 10M/100M | |
Perpetual Calendar | Built-in | ||
Cooling Method | Natural air circulation | ||
Safety Approval | CE / UL (Note 3) | ||
Waterproof Degree | IP65 / NEMA4 (Note 3) | ||
Operation Voltage
(Note2) |
DC +24V (-10% ~ +15%) (please use isolated power supply) | ||
Voltage Endurance | AC500V for 1 minute (between charging (DC24V terminal) and FG terminals) | ||
Power Consumption (Note 2) | 4.8W | 7.2W | |
Backup Battery | 3V lithium battery CR2032 x 1 | ||
Backup Battery Life | It depends on the temperature used and the conditions of usage,
about 3 years or more at 25oC. |
||
Operation Temperature | o o
0 C ~ 50 C |
||
Storage Temperature | o o
-20 C ~ +60 C |
||
Ambient Humidity | o o
10% ~ 90% RH [0 ~ 40 C], 10% ~ 55% RH [41 ~ 50 C], Pollution Degree 2 |
||
Vibration | IEC 61131-2 compliant 5Hz≦f<8.3Hz = Continuous: 3.5mm, 8.3Hz≦f≦150Hz = Continuous:
1.0g |
||
Shock | IEC 60068-2-27 compliant 15g peak for 11 ms duration, X, Y, Z directions for 6 times | ||
Dimensions
(W) x (H) x (D) mm |
129 x103 x 39 | ||
Panel Cutout
(W) x (H) mm |
118.8 x 92.8 | ||
Weight | Approx. 230g | Approx. 264g |
