| Type |
HF105F-1 |
HF105F-1 |
| Coil voltage form |
DC |
AC |
| Coil voltage |
15, 110, 12, 70, 18, 48, 9, 24, 6, 5 |
240, 208, 120, 24, 12, 277, 220 |
| Contact arrangement |
1 Form B, 1 Form C, 1 Form A |
1 Form A, 1 Form C, 1 Form B |
| Contact version |
Single contact |
Single contact |
| Terminal type |
Without Pin NO.6, Without Pin NO.6, With Pin no.6 |
With Pin no.6, Without Pin NO.6, Without Pin NO.6 |
| Construction |
Dust protected, Plastic sealed |
Dust protected, Plastic sealed |
| Terminals |
PCB |
PCB |
| Sort |
Single side stable |
Single side stable |
| Contact capacity |
AgSnO2, AgCdO |
AgSnO2, AgCdO |
| Insulation standard |
Class B, Class F |
Class B, Class F |
| Packing method |
Plastic tray |
Plastic tray |
| Rated voltage(V) |
240VAC |
240VAC |
| Coil angel form |
PCB |
PCB |
| Coil power |
Approx. 0.90 |
Approx. 2VA |
| Dielectric strength (between coil & contacts) (VAC 1min) |
2500 |
2500 |
| Operate time（ms） |
≤15 |
≤15 |
| Release time（ms） |
≤10 |
≤10 |
| Coil resistance（Ω） |
5:27,6:40,9:97,12:155,15:256,18:380,24:660,48:2560,70:5500,110:13450 |
12:25，24:100，120:2500，208:11000，220:13490,240:13490，277:15000 |
| Insulation resistance（MΩ） |
1000 |
1000 |
