| Type | HF115F-LS | |
| Coil voltage form | DC | |
| Coil voltage | 24, 6, 12, 9, 5 | |
| Contact arrangement | 1 Form A | |
| Contact version | bifurcated contacts | |
| Terminal type | PCB | |
| Mounting | PCB-THT | |
| Construction | Plastic sealed, Flux proofed | |
| Terminals | 3型脚位 | |
| Coil power | 标准型 | |
| Sort | 1 coil latching, 2 coil latching | |
| Contact capacity | W+AgSnO2 | |
| Insulation standard | Class F | |
| Packing method | Tube packing or tray packing | |
| Rated voltage(V) | 250VAC | |
| Coil power | 1 coil:Approx 0.4W 2 coil:Approx 0.6W |
|
| Dielectric strength (between coil & contacts) (VAC 1min) | 5000VAC 1min | |
| Operate time（ms） | ≤10 | |
| Release time（ms） | ≤10 | |
| Coil resistance（Ω） | 1 coil:5:62×（1±10%）Ω 6:90×（1±10%）Ω 9:202×（1±10%）Ω 12:360×（1±10%）Ω 24:1440×（1±10%）Ω;2 coil:5:42×（1±10%）Ω 6:55×（1±10%）Ω 9:135×（1±10%）Ω 12:240×（1±10%）Ω 24:886×（1±10%）Ω |
|
| Creepage Distance（mm） | 10 | |
| Electrical Distance（mm） | 10 | |
| Insulation resistance（MΩ） | 1000 | |
| Max. switching Current（AC） | 16 | |
| Max. switching voltage（VAC） | 440 | |
| Max. switching voltage（VDC） | 300 | |
| Ambient temperature (max)（℃） | -40 | |
| Ambient temperature (min)（℃） | 85 | |
| Length(mm) | 29.0 | |
| Width(mm) | 12.7 | |
| Heigh(mm) | 15.7 | |
| Mechanical endurance min | 2000000 | |
| Electrial eddurance min | 12000(See approval reports for more details) | |
| IEC60335-1 | YES | |
| Product Description | Clapper Type Electromagnetic Relay | |
| Application | Intelligent building, intelligent office, lighting control, etc | |
| Weight（g） | Aporox. 13.5 | |
| Volume（mm3） | 29.0×12.7×15.7 | |
| Product approval | VDE,UL,CQC | |
| File No. | VDE 116934,UL E134517,CQC CQC17002176310/CQC14002104529 |
