Hongfa Relay HF115F-Q

Series#: Hongfa Power relay

Product Details

Qty:

Specification

Type HF115F-Q
Coil voltage form DC
Coil voltage 5, 6, 60, 48, 12, 9, 18, 24
Contact arrangement 1 Form B, 1 Form A
Contact version single contact
Terminal type Quick connect terminals
Mounting PCB-THT
Construction Flux proofed
Terminals Quick connect terminals vertical
Coil power Approx 0.4W
Sort Standard
Contact capacity AgNi, AgSnO2
Insulation standard Class F
Packing method Tube packing or tray packing
Rated voltage(V) 250VAC
Coil power Approx 0.4W
Dielectric strength (between coil & contacts) (VAC 1min) 5000VAC 1min
Operate time(ms) ≤15
Release time(ms) ≤8
Coil resistance(Ω) 005:62×(1±10%)Ω
006:90×(1±10%)Ω
009:202×(1±10%)Ω
012:360×(1±10%)Ω
018:810×(1±10%)Ω
024:1440×(1±10%)Ω
048:5760×(1±15%)Ω
060:7500×(1±15%)Ω
Creepage Distance(mm) 8
Electrical Distance(mm) 8
Insulation resistance(MΩ) 1000
Max. switching Current(AC) 20
Max. switching voltage(VAC) 440
Max. switching voltage(VDC) 300
Ambient temperature (max)(℃) -40
Ambient temperature (min)(℃) 125
Length(mm) 41.0
Width(mm) 12.7
Heigh(mm) 15.7
Mechanical endurance min 10000000
Electrial eddurance min 30000(See approval reports for more details)
IEC60335-1 Yes
Product Description Clapper Type Electromagnetic Relay
Application appliances,etc
Weight(g) Aporox. 16
Volume(mm3) 41.0×12.7×15.7
Product approval VDE,UL,CQC
File No. VDE 116934,UL E134517,CQC CQC17002168381
