| Type | HF116F-3 | HF116F-3 |
| Coil voltage form | DC | AC |
| Coil voltage | 6, 12, 100, 200, 24, 3, 48, 110 | 48, 24, 6, 120, 220/240, 12 |
| Contact arrangement | 2H, 1H | 2H, 1H |
| Contact version | Single contact | Single contact |
| Terminal type | Screw | Screw |
| Construction | Flux proofed | Flux proofed |
| Terminals | Flanged, Mount | Mount, Flanged |
| Coil power | Standard | Standard |
| Sort | Single side stable | Single side stable |
| Contact capacity | AgSnO2, AgCdO | AgSnO2, AgCdO |
| Insulation standard | Class B, Class F | Class B, Class F |
| Special requirement | 3.0, 1.2 | 3.0, 1.2 |
| Packing method | plastics packing | plastics packing |
| Rated voltage(V) | 277VAC | 277VAC |
| Coil angel form | Screw | Screw |
| Coil power | Approx. 1.92 | Approx. 2.7 |
| Dielectric strength (between coil & contacts) (VAC 1min) | 4000 | 4000 |
| Operate time（ms） | ≤30 | ≤30 |
| Release time（ms） | ≤30 | ≤30 |
| Coil resistance（Ω） | 3:4.7；6:18.8；12:75；24:300；48:1200；100:5200；110:6300；200:21000 | 6:18.8；12:75；24:300；48:1200；120:5200；220/240:20800 |
| Creepage Distance（mm） | 8.0 | 8.0 |
| Electrical Distance（mm） | 8.0 | 8.0 |
| Insulation resistance（MΩ） | 1000 | 1000 |
| Max. switching Current（AC） | 1H:30 2H:25 |
1H:30 2H:25 |
| Max. switching voltage（VAC） | 277 | 277 |
| Ambient temperature (max)（℃） | -55 | -55 |
| Ambient temperature (min)（℃） | +70 | +70 |
| Length(mm) | 50.5 | 50.5 |
| Width(mm) | 32.9 | 32.9 |
| Heigh(mm) | 51 | 51.0 |
| Mechanical endurance min | 10000000 | 10000000 |
| Electrial eddurance min | 100000 | 100000 |
| Contact gap | Nil:1.2 W:3.0 |
Nil:1.2 W:3.0 |
| Product Description | Miniature High Power Relay | Miniature High Power Relay |
| Application | appliances,etc | appliances,etc |
| Weight（g） | Aporox. 120 | Aporox. 120 |
| Volume（mm3） | 50.5×32.9×51.0 | 50.5×32.9×51.0 |
| Product approval | UL,TUV,CQC | UL,TUV,CQC |
| File No. | UL:E134517,TUV:R 50154722,CQC:CQC09002031231 | UL:E134517,TUV:R 50154722,CQC:CQC09002031231 |
