Type | HF140FF | |
Coil voltage form | DC | |
Coil voltage | 12, 5, 6, 48, 24, 60, 3, 9, 18 | |
Contact arrangement | 2Form A, 2Form C | |
Contact version | single contact | |
Terminal type | PCB | |
Construction | Flux proofed, Plastic sealed | |
Coil power | Large contact gap, Standard | |
Contact capacity | AgSnO2, AgNi, AgCdO | |
Insulation standard | Class B, Class F | |
Contact plating | Gold Plated, No gold Plated | |
Packing method | Plastics packing | |
Coil power | W(456):1.4(Only for 2H),Standard:0.53,W:0.8 | |
Dielectric strength (between coil & contacts) (VAC 1min) | 5000VAC 1min | |
Operate time(ms) | 15 max | |
Release time(ms) | 5 max | |
Coil resistance(Ω) | Need to fill in respectively | |
Creepage Distance(mm) | 5 | |
Electrical Distance(mm) | 4 | |
Insulation resistance(MΩ) | 1000 | |
Max. switching Current(AC) | 10 | |
Max. switching voltage(DC) | 8 | |
Max. switching voltage(VAC) | 250 | |
Max. switching voltage(VDC) | 30 | |
Ambient temperature (max)(℃) | -40 | |
Ambient temperature (min)(℃) | 85 | |
Length(mm) | 29 | |
Width(mm) | 13 | |
Heigh(mm) | 26.3 | |
Mechanical endurance min | Standard:10000000,W:500000,W(456):300000 | |
Electrial eddurance min | 100000 | |
Contact gap | Standard:0.3,W:1.5,W(456):2.0(Only for 2H) | |
Product Description | Power relay |
