Type | HF14FF | |
Coil voltage form | DC | |
Coil voltage | 48, 6, 12, 9, 60, 18, 24, 3, 5 | |
Contact arrangement | 1 Form A, 1 Form C | |
Contact version | single contact | |
Terminal type | PCB | |
Mounting | PCB | |
Construction | Plastic sealed, Flux proofed | |
Contact capacity | AgCdO, AgSnO2, AgNi | |
Insulation standard | Class F, Class B | |
Packing method | Plastics packing | |
Rated voltage(V) | 277VAC, 30VDC | |
Coil power | 0.53 | |
Dielectric strength (between coil & contacts) (VAC 1min) | 5000 | |
Operate time(ms) | 15 max | |
Release time(ms) | 5 max | |
Coil resistance(Ω) | 003:17 005:47 006:68 009:160 012:275 018:650 024:1100 048:4170 060:7000 |
|
Creepage Distance(mm) | 6 | |
Electrical Distance(mm) | 6 | |
Insulation resistance(MΩ) | 1000 | |
Max. switching Current(AC) | 10 | |
Max. switching voltage(DC) | 10 | |
Max. switching voltage(VAC) | 277 | |
Max. switching voltage(VDC) | 30 | |
Ambient temperature (max)(℃) | -40 | |
Ambient temperature (min)(℃) | 70 | |
Length(mm) | 29 | |
Width(mm) | 13 | |
Heigh(mm) | 26 | |
Mechanical endurance min | 10000000 | |
Electrial eddurance min | 100000 | |
Explosion-proof certification | CNEx14.0245 | |
Contact gap | 0.4 min | |
Product Description | Power Relay |
