| Type | HF14FW | |
| Coil voltage form | DC | |
| Coil voltage | 12, 24, 18, 60, 9, 48, 5, 6 | |
| Contact arrangement | 1 Form B, 1 Form C, 1 Form A | |
| Contact version | single contact | |
| Terminal type | PCB | |
| Construction | Flux proofed, Plastic sealed | |
| Coil power | Sensitive, Standard | |
| Contact capacity | AgSnO2, AgCdO | |
| Insulation standard | Class F, Class F | |
| Packing method | Plastics packing | |
| Coil power | P:0.72，Nil:0.53 | |
| Dielectric strength (between coil & contacts) (VAC 1min) | 4000VAC 1min | |
| Operate time（ms） | 15 max | |
| Release time（ms） | 5 max |
