Type | HF170F | |
Coil voltage form | DC | |
Coil voltage | 6, 48, 12, 24, 9 | |
Contact arrangement | 2 Form A | |
Contact version | Single contact | |
Terminal type | PCB | |
Construction | Flux proofed | |
Coil power | Standard | |
Sort | Single side stable | |
Contact capacity | AgSnO2, AgNi | |
Insulation standard | Class F | |
Packing method | plastics packing | |
Rated voltage(V) | 277 | |
Coil angel form | PCB | |
Coil power | Standard:Approx. 1.88W | |
Dielectric strength (between coil & contacts) (VAC 1min) | 5000 | |
Operate time(ms) | ≤30 | |
Release time(ms) | ≤10 | |
Coil resistance(Ω) | Standard::6:19.1;9:43.1;12:76.6;24:306.4;48:1225.5 |
