Type | HF3F-L | |
Coil voltage form | DC | |
Coil voltage | 24, 5, 12, 48, 6, 9 | |
Contact arrangement | 1 Form A, 1 Form C | |
Contact version | Single contact | |
Terminal type | PCB | |
Mounting | PCB-THT | |
Construction | Flux proofed, Plastic sealed | |
Sort | 2 coil latching, 1 coil latching | |
Contact capacity | AgSnO2 | |
Polarity | Standard, Reverse Polarity | |
Packing method | carton packing | |
Rated voltage(V) | 250VAC | |
Coil angel form | PCB | |
Coil power | 1 coil:Approx. 0.4W 2 coil:Approx. 0.8W |
|
Dielectric strength (between coil & contacts) (VAC 1min) | 2000VAC 1min | |
Operate time(ms) | ≤8 | |
Release time(ms) | ≤5 | |
Coil resistance(Ω) | 1 coil:5:62.5×(1±10%)Ω 6:90×(1±10%)Ω 9:202.5×(1±10%)Ω 12:360×(1±10%)Ω 24:1440×(1±10%)Ω 48:5760×(1±10%)Ω;2 coil:5:31.5×(1±10%)Ω 6:45×(1±10%)Ω 9:101.5×(1±10%)Ω 12:180×(1±10%)Ω 24:720×(1±10%)Ω 48:2880×(1±10%)Ω |
