Hongfa Relay HF115F-H

Series#: Hongfa Power relay

Product Details

Qty:

Specification

Type HF115F-H
Coil voltage form DC
Coil voltage 48, 12, 5, 60, 18, 9, 6, 24
Contact arrangement 1 Form C, 1 Form B, 1 Form A
Contact version single contact
Terminal type PCB
Mounting PCB-THT
Construction Flux proofed, Plastic sealed
Terminals 5.0mm 1 pole 10A, 3.5mm 1 pole 10A, 5.0mm 1 pole 10A
Coil power Sensitive
Sort Standard
Contact capacity AgCdO, AgNi, AgSnO2
Insulation standard Class F
Contact plating Au plated, Without plating
Packing method Tube packing or tray packing
Rated voltage(V) 250V.a.c
Coil power Approx 0.25
Dielectric strength (between coil & contacts) (VAC 1min) 5000VAC 1min
Operate time(ms) ≤15
Release time(ms) ≤8
Coil resistance(Ω) 005:100×(1±10%)Ω
006:144×(1±10%)Ω
009:324×(1±10%)Ω
012:576×(1±10%)Ω
018:1296×(1±10%)Ω
024:2304×(1±10%)Ω
048:9216×(1±15%)Ω
060:12857×(1±15%)Ω
Creepage Distance(mm) 10
Electrical Distance(mm) 10
Insulation resistance(MΩ) 1000
Max. switching Current(AC) 1H:10A
1Z:10A
Max. switching voltage(VAC) 440VAC
Max. switching voltage(VDC) 300VDC
Ambient temperature (max)(℃) -40
Ambient temperature (min)(℃) 85
Length(mm) 29.0
Width(mm) 12.7
Heigh(mm) 15.7
Mechanical endurance min 10000000
