| Type | HF62F | |
| Coil voltage form | DC | |
| Coil voltage | 6, 24, 5, 12, 48, 18, 9 | |
| Contact arrangement | 1 Form A | |
| Contact version | single contact | |
| Terminal type | PCB&QC（Standard Type）, PCB | |
| Mounting | PCB&QC, PCB | |
| Construction | Flux proofed | |
| Sort | monostabillity | |
| Contact capacity | AgSnO2 | |
| Insulation standard | class F, class B | |
| Packing method | Plastics packing | |
| Rated voltage(V) | 250VAC/30VDC | |
| Coil power | 0.54 | |
| Dielectric strength (between coil & contacts) (VAC 1min) | 5000 | |
| Operate time（ms） | 20 max | |
| Release time（ms） | 10 max | |
| Coil resistance（Ω） | 005:47 006:68 009:155 012:270 018:620 024:1100 048:4400 |
|
| Creepage Distance（mm） | 9 | |
| Electrical Distance（mm） | 9 | |
| Insulation resistance（MΩ） | 1000 | |
| Max. switching Current（AC） | 16 | |
| Max. switching voltage（DC） | 16 | |
| Max. switching voltage（VAC） | 250 | |
| Max. switching voltage（VDC） | 30 | |
| Ambient temperature (max)（℃） | -40 | |
| Ambient temperature (min)（℃） | 85 | |
| Length(mm) | 29 | |
| Width(mm) | 12.6 | |
| Heigh(mm) | 24.2 | |
| Mechanical endurance min | 10000000 | |
| Electrial eddurance min | 100000 | |
| Contact gap | 0.4 min | |
| Product Description | Beat type electromagnetic relay | |
| Application | home appliances | |
| Weight（g） | Approx 15 | |
| Volume（mm3） | 29×12.6×24.2 | |
| Product approval | CQC，UL，TUV | |
| File No. | CQC CQC09002028470，UL E133481，TUV R50147086 |
