| Type |
HF7520 |
|
| Coil voltage form |
DC |
|
| Coil voltage |
6, 18, 24, 48, 5, 9, 12 |
|
| Contact arrangement |
1 Form C, 1 Form A |
|
| Contact version |
single contact |
|
| Terminal type |
QC, PCB |
|
| Mounting |
QC, Nil |
|
| Construction |
Flux proofed, Plastic sealed |
|
| Coil power |
Standard |
|
| Sort |
Single side stable |
|
| Contact capacity |
AgSnO2, AgCdO |
|
| Insulation standard |
Class F, Class F |
|
| Contact plating |
Without plating |
|
| Packing method |
Carton packing or Plast packing |
|
| Rated voltage(V) |
250Va.c. |
|
| Dielectric strength (between coil & contacts) (VAC 1min) |
2500VAC 1min |
|
| Operate time（ms） |
≤15 |
|
| Release time（ms） |
≤5 |
|
| Creepage Distance（mm） |
3.2 |
|
| Electrical Distance（mm） |
1.6 |
|
| Insulation resistance（MΩ） |
1000 |
|
| Max. switching Current（AC） |
16 |
|
| Max. switching voltage（DC） |
10 |
|
| Max. switching voltage（VAC） |
250VAC |
|
| Max. switching voltage（VDC） |
30VDC |
