Type | HF7FD | |
Coil voltage form | DC | |
Coil voltage | 12, 18, 6, 3, 5, 48, 36, 9, 24 | |
Contact arrangement | 1 Form C, 1 Form A | |
Contact version | single contact | |
Terminal type | PCB | |
Mounting | PCB-THT | |
Construction | Flux proofed, Plastic sealed | |
Coil power | Standard | |
Sort | Single side stable | |
Contact capacity | AgCdO, AgSnO2 | |
Insulation standard | Class F, Class B | |
Contact plating | Without plating, Au plated | |
Packing method | Tube packing or Carton packing | |
Rated voltage(V) | 277V.a.c | |
Coil power | Approx 0.36 | |
Dielectric strength (between coil & contacts) (VAC 1min) | 2500VAC 1min | |
Operate time(ms) | ≤10 | |
Release time(ms) | ≤5 | |
Creepage Distance(mm) | 3.2 | |
Electrical Distance(mm) | 1.6 | |
Insulation resistance(MΩ) | 100 | |
Max. switching Current(AC) | 16 | |
Max. switching voltage(DC) | 10 | |
Max. switching voltage(VAC) | 277VAC | |
Max. switching voltage(VDC) | 28VDC | |
Ambient temperature (max)(℃) | -40 | |
Ambient temperature (min)(℃) | 105 | |
Length(mm) | 22.0 | |
Width(mm) | 16.0 | |
Heigh(mm) | 16.4 | |
Mechanical endurance min | 10000000 | |
Electrial eddurance min | 100000(See approval reports for more details) | |
IEC60335-1 | YES | |
Product Description | Clapper Type Electromagnetic Relay | |
Application | appliances,intelligent home,Thermostat,etc | |
Weight(g) | Aporox. 9.5 | |
Volume(mm3) | 22.0×16.0×16.4 |
