| Type |
HF94F |
HF94F |
| Coil voltage form |
DC |
AC |
| Coil voltage |
6, 48, 9, 24, 12, 120 |
277, 48, 24, 12, 120, 6, 240 |
| Contact arrangement |
1 Form C, 1 Form A+1 Form B, 1 Form B, 1 Form A |
1 Form B, 1 Form C, 1 Form A, 1 Form A+1 Form B |
| Contact version |
Single contact |
Single contact |
| Terminal type |
QC |
QC |
| Mounting |
Flang, Mounting Distance 66.7mm. diameter Φ4.8mm, Flang, Mounting Distance 54.8mm. diameter Φ3.8mm, Metal Bracket |
Metal Bracket, Flang, Mounting Distance 54.8mm. diameter Φ3.8mm, Flang, Mounting Distance 66.7mm. diameter Φ4.8mm |
| Construction |
Dust protected |
Dust protected |
| Terminals |
QC |
QC |
| Sort |
Single side stable |
Single side stable |
| Contact capacity |
AgCdO, AgCe |
AgCe, AgCdO |
| Insulation standard |
Class F |
Class F |
| Rated voltage(V) |
277VAC |
277VAC |
| Coil angel form |
QC |
QC |
| Coil power |
Approx. 2.4W |
Approx. 4.0VA |
| Dielectric strength (between coil & contacts) (VAC 1min) |
2000 |
2000 |
| Coil resistance（Ω） |
6:17.5，9:40，12:70，24:280，48:1120，120:7000 |
6:4.8，12:19，24:77，48:280，120:2000，240:7250，277:11000 |
| Insulation resistance（MΩ） |
500 |
500 |
| Max. switching Current（AC） |
18 |
18 |
| Max. switching voltage（VAC） |
277 |
277 |
| Ambient temperature (max)（℃） |
-40 |
-40 |
| Ambient temperature (min)（℃） |
65 |
65 |
| Length(mm) |
47.0 |
47.0 |
| Width(mm) |
32.0 |
32.0 |
| Heigh(mm) |
28.5 |
28.5 |
| Mechanical endurance min |
1000000 |
1000000 |
| Electrial eddurance min |
50000 |
50000 |
| Product Description |
High Power Relay |
High Power Relay |
| Weight（g） |
Approx. 85 |
Approx. 85 |
| Volume（mm3） |
47.0×32.0×28.5 |
47.0×32.0×28.5 |
| Product approval |
UL |
UL |
| File No. |
UL:E134517 |
UL:E134517 |
