| Type | HFA4 | |
| Coil voltage form | DC | |
| Coil voltage | 24, 12, 48, 6, 9, 18, 36 | |
| Contact arrangement | 3Form A+1Form B, 2Form A+2Form B | |
| Contact version | Single contact | |
| Terminal type | PCB | |
| Construction | Flux proofed | |
| Sort | Single side stable | |
| Contact capacity | AgSnO2 | |
| Insulation standard | F级, B级 | |
| Contact plating | & x1C;& x06;Gold Plated, No gold Plated |
|
| Packing method | plastics packing | |
| Rated voltage(V) | 250VAC | |
| Coil angel form | PCB | |
| Coil power | Approx.0.36W | |
| Dielectric strength (between coil & contacts) (VAC 1min) | 4000VAC 1min | |
| Operate time（ms） | ≤20 | |
| Release time（ms） | ≤20 | |
| Coil resistance（Ω） | 6:100；9:225；12:400；18:900；24:1600;36:3600;48:6400 | |
| Creepage Distance（mm） | 8 | |
| Electrical Distance（mm） | 5.5 | |
| Insulation resistance（MΩ） | 1000 | |
| Max. switching Current（AC） | 6 | |
| Max. switching voltage（DC） | 6 | |
| Max. switching voltage（VAC） | 400 | |
| Max. switching voltage（VDC） | 30 | |
| Ambient temperature (max)（℃） | -40 | |
| Ambient temperature (min)（℃） | +85 | |
| Length(mm) | 40 | |
| Width(mm) | 13 | |
| Heigh(mm) | 24 | |
| Mechanical endurance min | 10000000 | |
| Electrial eddurance min | 100000 | |
| Contact gap | Nil:0.8 | |
| Product Description | Safety relay |
