| Type | HFD16 | |
| Coil voltage form | DC | |
| Coil voltage | 5, 3, 18, 6, 9, 4.5, 12, 24, 2.4 | |
| Contact arrangement | 1 Form C | |
| Contact version | Single contact | |
| Terminal type | DIP | |
| Mounting | DIP | |
| Construction | & x0E;& x0F;Flux proofed, Plastic sealed |
|
| Coil power | Standard(0.45W), High sensitive& x0F;& x08;& x1B;& x0F;(0.2W), Sensitive(0.36W) |
|
| Sort | Monostable | |
| Contact capacity | AgSnO2, AgNi | |
| Insulation standard | F | |
| Contact plating | Au plated, No Au plated | |
| Packing method | Tube packing | |
| Coil power | Approx.0.2 Approx.0.36 Approx.0.45 |
|
| Dielectric strength (between coil & contacts) (VAC 1min) | 1000VAC 1min | |
| Operate time（ms） | ≤10 | |
| Release time（ms） | ≤5 | |
| Coil resistance（Ω） | 分别填写 | |
| Insulation resistance（MΩ） | 1000 | |
| Max. switching voltage（DC） | 8 | |
| Max. switching voltage（VAC） | 250 | |
| Max. switching voltage（VDC） | 220 | |
| Ambient temperature (max)（℃） | -40 | |
| Ambient temperature (min)（℃） | 85 | |
| Length(mm) | 15.7 | |
| Width(mm) | 10.6 | |
| Heigh(mm) | 11.8 | |
| Mechanical endurance min | 10000000 | |
| Electrial eddurance min | 100000(See approval reports for more details) | |
| IEC60335-1 | YES | |
| Product Description | Monostable non-polarized DC electromagnetic relay. | |
| Application | Security (video monitoring, gas alarm, access control, video intercom, etc.), office equipment, small appliances and other fields | |
| Weight（g） | Approx.4 | |
| Volume（mm3） | 15.7×10.6×11.8 | |
| Product approval | UL,TUV | |
| File No. | UL E133481,TUV R50075326 |
