Hongfa Relay HFE15

Series#: Hongfa Latching Relay

Product Details

  •  Laching relay
  •  20A switching capacity
  •  lnrush current Capacitor 430A/1.5ms
  •  Environmental friendly product (RoHS compliant)
  •  Outline Dimensions: 37.3mm x 13.1mm x28.8mm
Qty:

Specification

Type HFE15
Coil voltage form DC
Coil voltage 12, 3, 9, 48, 24, 5, 6
Contact arrangement 1 Form C, 1 Form B , 1 Form A
Contact version Single contact
Terminal type Standard PCB terminal
Mounting Mounting plate
Construction Non-plastic seal type
Terminals Standard
Coil power Standard
Sort Double coil latching, Single coil latching
Contact capacity AgSnO2
Insulation standard Class F
Contact plating No coating
Polarity Reversed Polarity, Standard Polarity
Rated voltage(V) 250
Coil angel form Standard
Coil power 1 coil latching:0.7W
2 coil latching:1.5W
Dielectric strength (between coil & contacts) (VAC 1min) 4000VAC 1min
Operate time(ms) ≤15
Release time(ms) ≤15
Coil resistance(Ω) 12.5×(1±10%)
34.5×(1±10%)
50×(1±10%)
112.5×(1±10%)
200×(1±10%)
800×(1±10%)
3200×(1±10%)
2×6×(1±10%)
2×17.5×(1±10%)
2×25×(1±10%)
2×54×(1±10%)
2×100×(1±10%)
2×400×(1±10%)2×1600×(1±10%)
Creepage Distance(mm) 8
Electrical Distance(mm) 5.5
Insulation resistance(MΩ) 1000
Max. switching Current(AC) 20
Max. switching voltage(VAC) 250
Ambient temperature (max)(℃) -25
Ambient temperature (min)(℃) 70
Length(mm) 37.3
Width(mm) 13.1
Heigh(mm) 25.8
Mechanical endurance min 1000000
Electrial eddurance min 100000
Contact gap ≥0.8
Product Description Miniautre High Power latching relay
