| Type | HFE16 | |
| Coil voltage form | DC | |
| Coil voltage | 24, 9, 6, 48, 12 | |
| Contact arrangement | 3 Form A, 3Form B | |
| Contact version | Double contact | |
| Terminal type | Special QC terminal | |
| Mounting | Mounting screw | |
| Construction | Non-plastic seal type | |
| Terminals | Standard | |
| Coil power | Standard | |
| Sort | Double coil, Single coil | |
| Contact capacity | AgSnO2 | |
| Insulation standard | Class F | |
| Contact plating | No coating | |
| Polarity | Reversed Polarity, Standard Polarity | |
| Rated voltage(V) | 277 | |
| Coil angel form | Standard | |
| Coil power | 5W 10W |
|
| Dielectric strength (between coil & contacts) (VAC 1min) | 4000VAC 1min | |
| Operate time（ms） | ≤30 | |
| Release time（ms） | ≤30 | |
| Coil resistance（Ω） | 7×（1±10%）Ω 16×（1±10%）Ω 29×（1±10%）Ω 115×（1±10%）Ω 460×（1±10%）Ω 2×、3.5×（1±10%）Ω 2×8×（1±10%）Ω 2×57.5×（1±10%）Ω 2×230×（1±10%）Ω |
|
| Creepage Distance（mm） | 8.4 | |
| Electrical Distance（mm） | 6.4 | |
| Insulation resistance（MΩ） | 1000 | |
| Max. switching Current（AC） | 120 | |
| Max. switching voltage（VAC） | 277 | |
| Ambient temperature (max)（℃） | -40 | |
| Ambient temperature (min)（℃） | 70 | |
| Length(mm) | 115 | |
| Width(mm) | 48 | |
| Heigh(mm) | 26 | |
| Mechanical endurance min | 100000 | |
| Electrial eddurance min | 5000 | |
| Contact gap | ≥1 | |
| Product Description | High Power Relay |
