| Type | HFE21 | |
| Coil voltage form | DC | |
| Coil voltage | 9, 12, 24, 48, 6 | |
| Contact arrangement | 1 Form B, 1 Form A | |
| Contact version | Single contact | |
| Terminal type | Special QC terminal | |
| Mounting | Mounting screw | |
| Construction | Non-plastic seal type | |
| Terminals | B contant elicitation, A contant elicitation, C contant elicitation, J contant elicitation, D contant elicitation, G contant elicitation, I contant elicitation | |
| Coil power | Standard | |
| Sort | Single coil, Double coil | |
| Contact capacity | AgSnO2 | |
| Insulation standard | Class F | |
| Contact plating | No coating | |
| Polarity | Reversed Polarity, Standard Polarity | |
| Rated voltage(V) | 220 | |
| Coil angel form | Standard | |
| Coil power | 3W 6W |
|
| Dielectric strength (between coil & contacts) (VAC 1min) | 4000VAC 1min | |
| Operate time（ms） | ≤20 | |
| Release time（ms） | ≤20 | |
| Coil resistance（Ω） | 13×（1±10%）Ω 27×（1±10%）Ω 50×（1±10%）Ω 108×（1±10%）Ω 210×（1±10%）Ω 860×（1±10%）Ω 2×6.5×（1±10%）Ω 2×13.5×（1±10%）Ω 2×25×（1±10%）Ω 2×54×（1±10%）Ω 2×105×（1±10%）Ω 2×430×（1±10%）Ω |
|
| Creepage Distance（mm） | 8.4 | |
| Electrical Distance（mm） | 6.4 | |
| Insulation resistance（MΩ） | 1000 | |
| Max. switching Current（AC） | 100 | |
| Max. switching voltage（VAC） | 220 | |
| Ambient temperature (max)（℃） | -40 | |
| Ambient temperature (min)（℃） | 85 | |
| Length(mm) | 52 | |
| Width(mm) | 43 | |
| Heigh(mm) | 22 | |
| Mechanical endurance min | 100000 | |
| Electrial eddurance min | 5000 | |
| Contact gap | ≥0.95 | |
| Product Description | Miniautre High Power latching relay |
