| Type | HFE25 | |
| Coil voltage form | DC | |
| Coil voltage | 12, 24, 48, 6 | |
| Contact arrangement | 2 Form A, 2 Form B | |
| Contact version | double contact | |
| Terminal type | B, A | |
| Construction | unsealed | |
| Coil power | Standard form | |
| Sort | single coil, double coil | |
| Contact capacity | AgSnO2, AgSnO2In2O3 | |
| Polarity | Standard polarity, Reversed polarity | |
| Rated voltage(V) | 230Va.c. | |
| Coil power | single coil:12W double coil :24W |
|
| Dielectric strength (between coil & contacts) (VAC 1min) | 4000VAC(1min) | |
| Operate time（ms） | ≤20ms | |
| Release time（ms） | ≤20ms | |
| Coil resistance（Ω） | 3×（-8%~-3%）Ω 12×（-8%~-3%）Ω 48×（-8%~-3%）Ω 190×（-8%~-3%）Ω 2×1.5×（-8%~-3%）Ω 2×6×（-8%~-3%）Ω 2×24×（-8%~-3%）Ω 2×95×（-8%~-3%）Ω |
|
| Creepage Distance（mm） | 8.4mm | |
| Electrical Distance（mm） | 6.4mm | |
| Insulation resistance（MΩ） | 1000MΩ | |
| Max. switching Current（AC） | 200A | |
| Max. switching voltage（DC） | 30VDC | |
| Max. switching voltage（VAC） | 440VAC | |
| Max. switching voltage（VDC） | 30VDC | |
| Ambient temperature (max)（℃） | -40℃ | |
| Ambient temperature (min)（℃） | 70℃ | |
| Length(mm) | 73.3mm | |
| Width(mm) | 74.8mm | |
| Heigh(mm) | 29.5mm | |
| Mechanical endurance min | 1×105 | |
| Electrial eddurance min | 5000(impedance) | |
| Contact gap | 1.2mm | |
| Product Description | High Power Relay |
