Type | HFE31 | |
Coil voltage form | DC | |
Coil voltage | 12, 9, 24, 48, 6 | |
Contact arrangement | 1 Form B, 1 Form A | |
Contact version | Double contact | |
Terminal type | Special QC terminal | |
Mounting | Mouting bossl, No mouting boss | |
Construction | Non-plastic seal type | |
Terminals | Standard | |
Coil power | Standard form | |
Sort | Double coil, Single coil | |
Contact capacity | AgSnO2 | |
Insulation standard | Class F | |
Contact plating | No coating | |
Polarity | Standard Polarity, Reversed Polarity | |
Rated voltage(V) | 250 | |
Coil power | 5.0W 10.0W |
|
Dielectric strength (between coil & contacts) (VAC 1min) | 4000VAC 1min | |
Operate time(ms) | ≤20 | |
Release time(ms) | ≤20 | |
Coil resistance(Ω) | 7.2×(1±8%)Ω 16.2×(1±8%)Ω 28.8×(1±8%)Ω 115.2×(1±8%)Ω 460.8×(1±8%)Ω 2×3.6×(1±8%)Ω 2×8.1×(1±8%)Ω 2×14.4×(1±8%)Ω 2×57.6×(1±8%)Ω 2×230.4×(1±8%)Ω |
|
Creepage Distance(mm) | 8.4 | |
Electrical Distance(mm) | 6.4 | |
Insulation resistance(MΩ) | 1000 | |
Max. switching Current(AC) | 200 | |
Max. switching voltage(VAC) | 250 | |
Ambient temperature (max)(℃) | -40 | |
Ambient temperature (min)(℃) | 70 | |
Length(mm) | 61.3 | |
Width(mm) | 57 | |
Heigh(mm) | 29.3 | |
Mechanical endurance min | 100000 | |
Electrial eddurance min | 5000 | |
Contact gap | 1.3 | |
Product Description | Miniautre High Power latching relay |
