| Type | HFE46 | |
| Coil voltage form | DC | |
| Coil voltage | 24, 12, 3, 9, 6, 5 | |
| Contact arrangement | 1 Form B, 1 Form A | |
| Contact version | Single contac | |
| Terminal type | Standard PCB terminal | |
| Construction | Plastic seal type, Non-plastic seal type | |
| Terminals | Standard | |
| Coil power | Standard | |
| Sort | 1 coil latching, 2 coil latching | |
| Contact capacity | AgSnO2 | |
| Insulation standard | Class F | |
| Contact plating | Standard | |
| Polarity | Reversed Polarity, Standard Polarity | |
| Rated voltage(V) | 250 | |
| Coil angel form | Standard | |
| Coil power | single :0.4Wt double::0.8W |
|
| Dielectric strength (between coil & contacts) (VAC 1min) | 4000VAC 1min | |
| Operate time（ms） | ≤10 | |
| Release time（ms） | ≤10 | |
| Coil resistance（Ω） | 0.4W:3:22.5×（1±10%）Ω 5:62.5×（1±10%）Ω 6:90×（1±10%）Ω 9:202.5×（1±10%）Ω 12:360×（1±10%）Ω 24:1440×（1±10%）Ω 0.8W:3:2-11.25×（1±10%）Ω 5:2-31.25×（1±10%）Ω 6:2-45×（1±10%）Ω 9:2-101.25×（1±10%）Ω 12:2-180×（1±10%）Ω 24:2-720×（1±10%）Ω |
|
| Creepage Distance（mm） | 15 | |
| Electrical Distance（mm） | 6.4 | |
| Insulation resistance（MΩ） | 1000 | |
| Max. switching Current（AC） | 16 | |
| Max. switching voltage（VAC） | 277 | |
| Ambient temperature (max)（℃） | -40 | |
| Ambient temperature (min)（℃） | 85 | |
| Length(mm) | 29 | |
| Width(mm) | 13 | |
| Heigh(mm) | 15.7 | |
| Mechanical endurance min | 1000000 | |
| Electrial eddurance min | 100000 | |
| Manual operation | Without manual switch | |
| Contact gap | ≥0.3 | |
| Product Description | Miniautre High Power latching relay |
