| Type | HFE66-100 | |
| Coil voltage form | DC | |
| Coil voltage | 5, 48, 12, 6, 9, 24 | |
| Contact arrangement | 1 Form A | |
| Contact version | Single contact | |
| Terminal type | Special QC terminal | |
| Mounting | Mounting screw | |
| Construction | Non-plastic seal type | |
| Terminals | 3 contant elicitation, 1 contant elicitation, 2 contant elicitation, 4 contant elicitation | |
| Coil power | Standard | |
| Sort | Single coil, Double coil | |
| Contact capacity | AgSnO2 | |
| Insulation standard | Class F | |
| Contact plating | No coating | |
| Polarity | Standard Polarity, Reversed Polarity | |
| Rated voltage(V) | 250 | |
| Coil angel form | Standard | |
| Coil power | 2.5W 5.0W |
|
| Dielectric strength (between coil & contacts) (VAC 1min) | 4000VAC 1min | |
| Operate time（ms） | ≤6 | |
| Release time（ms） | ≤6 | |
| Coil resistance（Ω） | 10×（1±10%）Ω 14.4×（1±10%）Ω 32.4×（1±10%）Ω 57.6×（1±10%）Ω 230.4×（1±10%）Ω 921.6×（1±10%）Ω 2×5×（1±10%）Ω 2×7.2×（1±10%）Ω 2×16.2×（1±10%）Ω 2×28.8×（1±10%）Ω 2×115.2×（1±10%）Ω 2×460.8×（1±10%）Ω |
|
| Creepage Distance（mm） | 8.4 | |
| Electrical Distance（mm） | 6.4 | |
| Insulation resistance（MΩ） | 1000 | |
| Max. switching Current（AC） | 100 | |
| Max. switching voltage（VAC） | 380 | |
| Ambient temperature (max)（℃） | -45 | |
| Ambient temperature (min)（℃） | 85 | |
| Length(mm) | 40.2 | |
| Width(mm) | 30.8 | |
| Heigh(mm) | 16.5 | |
| Mechanical endurance min | 1000000 | |
| Electrial eddurance min | 6000 | |
| Contact gap | ≥1.1 | |
| Product Description | Miniautre High Power latching relay |
