Type | HFV6 | |
Coil voltage form | DC | |
Coil voltage | 12VDC, 24VDC | |
Contact arrangement | 1 Form A, 1 Form C | |
Terminal type | QC | |
Construction | Plastic sealed, Dust proctected | |
Coil power | Sentive, Standard | |
Sort | Single side stable | |
Contact capacity | AgSnO2 | |
Parallel coil components | resistance, diode, Nil | |
Packing method | Tube packing or plastics packing | |
Rated voltage(V) | 24, 12 | |
Coil power | 1.8 | |
Dielectric strength (between coil & contacts) (VAC 1min) | 500VAC 1min | |
Operate time(ms) | ≤10 | |
Release time(ms) | ≤10 | |
Coil resistance(Ω) | 12VDC:90×(1±10%) 12VDC:124×(1±10%) 24VDC:360×(1±10%) 24VDC:441×(1±10%) |
|
Insulation resistance(MΩ) | 100 |
