Type | HFV9 | |
Coil voltage form | DC | |
Coil voltage | 24, 12 | |
Contact arrangement | 1 Form A, 1 Form C | |
Contact version | single contact | |
Terminal type | QC(280) | |
Mounting | Plug-in mounting | |
Construction | Plastic sealed, Flux proofed | |
Terminals | 2.8 mm 1 pole 20 A | |
Coil power | Standard | |
Sort | Single side stable | |
Contact capacity | AgSnO2In2O3 | |
Insulation standard | Class H | |
Parallel coil components | resistor, none, diode | |
Contact plating | Au plated, Without plating | |
Packing method | Tube packing or plastics packing | |
Rated voltage(V) | 27, 13.5 | |
Coil power | 1.3 1.6 |
|
Dielectric strength (between coil & contacts) (VAC 1min) | 500 | |
Operate time(ms) | ≤10 | |
Release time(ms) | 12 Vd.c.≤10,24 Vd.c.≤15 | |
Coil resistance(Ω) | “12Vd.c.:109×(1±10%),24Vd.c.:360×(1±10%)” | |
Insulation resistance(MΩ) | 100 | |
Max. switching voltage(DC) | 30 | |
Max. switching voltage(VDC) | 40 | |
Ambient temperature (max)(℃) | -40 | |
Ambient temperature (min)(℃) | 125 | |
Length(mm) | 22.5 | |
Width(mm) | 15 | |
Heigh(mm) | 25 | |
Mechanical endurance min | 10000000 | |
Electrial eddurance min | 100000(See approval reports for more details) | |
Contact gap | 0.25-0.5,0.6-0.8 | |
Product Description | Clapper Type Electromagnetic Relay |
