Model | IL-1000 | IL-1500 | IL-1050 | IL-1550 |
Type | DIN-rail mount | Panel mount | DIN-rail mount | Panel mount |
Main unit/expansion unit | Main unit | Expansion unit | ||
Head compatibility | Compatible | |||
Display Minimum displayable unit | IL-030: 1 μm, IL-065/IL-100: 2 μm, IL-300: 10 μm, IL-600: 50 μm, IL-2000: 100 μm 3.94″ | |||
Display range | IL-030/IL-065/IL-100: ±99.999 mm to ±99 mm (4 levels selectable), IL-300/IL-600: ±999.99 mm to ±999 mm (3 levels selectable), IL-2000: ±9999.9 mm to ±9999 mm (2 levels selectable) | |||
Display rate | Approx. 10 times/sec. | |||
Analog voltage output 1. | ±5 V, 1 to 5 V, 0 to 5 V Output impedance 100 Ω | None | ||
Analog current output 1. | 4 to 20 mA Maximum load resistance of 350 Ω | |||
Control input 2.
Bank switch input |
Non-voltage input |
|||
Zero-shift input | ||||
Stop emission input | ||||
Timing input | ||||
Reset input | ||||
Judgement output | Open collector output (NPN, PNP changeover possible/N.O., N.C. changeover possible) | |||
Alarm output | Open collector output (NPN, PNP changeover possible/N.C.) | |||
Current Power voltage 4. | 10 to 30 VDC ripple (P-P) 10% included, Class 2 | Supplied by main unit | ||
Power consumption | 2300 mW or less (at 30 V: 77 mA or less) | 2500 mW or less (at 30 V: 84 mA or less) | 2000 mW or less (at 30 V: 67 mA or less) | 2200 mW or less (at 30 V: 74 mA or less) |
Ambient humidity | -10 to +50°C 14 to 122°F (No condensation or freezing) | |||
Ambient temperature | 35 to 85% RH (No condensation) | |||
Vibration | 10 to 55 Hz Double amplitude 1.5 mm 0.06″ XYZ each axis: 2 hours | |||
Pollution degree | 2 | |||
Material | Case / Front sheet: Polycarbonate; Key tops: Polyacetel; Cable: PVC | |||
Weight (including attachments) | Approx. 150g | Approx. 170g | Approx. 140g | Approx. 160g |
