Model NPN output | GT2-100N | GT2-E3N |
PNP output | GT2-100P | GT2-E3P |
Mounting type | Panel mount | – |
Number of connectable heads |
2 heads with GT2-100N(P) alone
+ 3 heads per 1 head board expansion When expanded with a maximum of 3 head boards, 11 heads |
– |
Power supply voltage | 10 to 30 VDC, including 10% ripple (P-P), Class 2 | Supplied from the GT2-100N/100P |
Display range | -199.999.9 to 199.999.9 | – |
Display resolution | 0.1 μm | – |
Normal | 4500 mW or less (150.0 mA or less at 30 V) | 4200 mW or less (140.0 mA or less at 30 V) |
Power saving (Eco half) *1 | 3700 mW or less (123.3 mA or less at 30 V) | 4200 mW or less (140.0 mA or less at 30 V) |
Power saving (Eco all)*1 | 3600 mW or less (120.0 mA or less at 30 V) | 4000 mW or less (133.3 mA or less at 30 V) |
Response time | hsp (3)/5/10/100/500/1000 ms
(When using GT2-Pxxx, hsp (12)/20/40/400/2000/4000 ms) |
|
Input/output connector *2 | Power supply: Terminal block connection Input/output: 20-pin connector (MIL standard) | 30-pin connector (MIL standard) |
Ambient temperature | -10 to +50°C 14 to 122°F (No freezing) | |
Relative humidity | 35 to 85% RH (No condensation) | |
Vibration | 10 to 55 Hz Double amplitude 0.15 mm 0.01″ in the X, Y, Z axis directions respectively, 2 hours | |
Materials |
Main body case/front cover: polycarbonate (PC), Key top: polyacetal (POM),
Front sheet: polyethylene terephthalate (PET) |
– |
Weight | Approx. 380 g | Approx. 80 g |
Model Main unit | GT2-500 |
Expansion unit | GT2-550 |
Mounting type *1 | DIN-rail mount |
Number of expansion units *2 | Maximum of 3 units including the main unit (Maximum of 15 sensor heads) |
Power supply voltage | 20 to 30 VDC, including 10% ripple (P-P) (GT2-550 power supplied from the main unit), Class 2 |
Consumption current | 4800 mW
160.0 mA or less at 30 V |
Response time | hsp (3)/5/10/100/500/1000 ms
(When using GT2-Pxxx, hsp (12)/20/40/400/2000/4000 ms) |
Imbient temperature | -10 to +50°C 14 to 122°F |
Relative humidity | 35 to 85% RH (No condensation) |
Vibration | 10 to 55 Hz Double amplitude 1.5 mm 0.06″ in the X, Y, Z axis directions respectively, 2 hours |
Materials | Main body case: polycarbonate, Cable: PVC |
Weight | GT2-500: Approx. 140 g, GT2-550: Approx. 95 g |
