Keyence Digital CMOS Laser Sensor GV-H1000 GV-H1000L

Keyence Digital CMOS Laser Sensor GV-H1000 GV-H1000L

Series#: Keyence Digital CMOS Laser Sensor GV-H1000 GV-H1000L

Product Details

Keyence Digital CMOS Laser Sensor GV-H1000 GV-H1000L
We are First Class Keyence sensor dealer and Keyence sensor distributor in China.
We can Supply all kinds of Keyence sensor parts,such as Keyence Digital Laser Sensors,Keyence Vision Sensors,Keyence Fiber Optic Sensors,Keyence Inductive Proximity Sensors,Keyence Photoelectric Sensors,Keyence Positioning Sensors and So on.
All parts are 100% Original and new in stock by Keyence and fast delivery time within 1 day
100% after sale service and technology Support
MOQ: 1pcs

Qty:

Add to Enquiry Cart

Specification

Download A Munual

Model	GV-H45	GV-H45L	GV-H130	GV-H130L	GV-H450	GV-H450L	GV-H1000	GV-H1000L
Type	Short-range		Mid-range		Long-range		Ultra long-range
Light source	Visible semiconductor laser, Wavelength: 655 nm
FDA (CDRH) Part 1040.10	Class 2 (560 µW)	Class 1^*3 (220 µW)	Class 2 (560 µW)	Class 1^*3 (220 µW)	Class 2 (560 µW)	Class 1^*3 (220 µW)	Class 2 (560 µW)	Class 1^*3 (220 µW)
IEC 60825-1		Class 1 (220 µW)		Class 1 (220 µW)		Class 1 (220 µW)		Class 1 (220 µW)
JIS C6802
Detection distance (Amplifier display )	20 to 45 mm 0.79″ to 1.77″ (250 to 0)^*1)		55 to 130 mm 2.17″ to 5.12″ (750 to 0)^*1)		160 to 450 mm 6.30″ to 17.72″ (290 to 0)^*1)		200 to 1000 mm 7.87″ to 39.37″ (800 to 0)^*1)
Possible display range	259 to -34		768 to -98		295 to -50		810 to -175
Standard detection deviation	0.5 mm 0.02″		1 mm 0.04″		3 mm 0.12″		20 mm 0.79″ (Detection distance 200 to 800 mm 7.87″ to 31.5″) 30 mm 1.18″ (Detection distance 800 to 1000 mm 31.5″ to 39.37″)
Spot diameter	Approx. ø0.1 mm ø0.004″ (Detection distance 45 mm 1.77″)		Approx. ø0.3 mm ø0.012″ (Detection distance 130 mm 5.12″)		Approx. ø0.8 mm ø0.031″ (Detection distance 450 mm 17.72″)		Approx. ø1.8 mm ø0.07″ (Detection distance 1000 mm 39.37″)
Operation status indicators	Control output: Red LED/Laser radiation emission indicator: Green LED/1 spot indicator: Green LED
Environmental resistanceEnclosure rating	IP67
Ambient temperature	-10 to +50 °C 14 to 122 °F (No freezing)
Relative humidity	35 to 85 % RH (No condensation)
Vibration resistance	10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z axis
Material	Housing material: PBT, Display: Polyarylate, Metal: SUS304, Lens cover: Glass, Cable: PVC
Weight	Approx. 120 g^*2		Approx. 130 g^*2		Approx. 190 g^*2		Approx. 210 g^*2
