Keyence Fiber Optic Sensors FU-51TZ FU-52TZ FU-53TZ FU-54TZ FU-56TZ FU-57TZ FU-57TE

Series#: Keyence Fiber Optic Sensors

Product Details

Qty:

Specification

Model FU-51TZ*1
Optical axis diameter
(Standard target to be detected)
ø0.5 mm0.02″
Beam emitting direction Top
Fibre unit length 1 m39.37″ free-cut
Fibre unit diameter ø1.0
Minimum bend radius R2 mm0.079″ Tough-Flex
Minimum detectable object Object with a diameter of 0.005 mm0.0002″*2
Environmental resistance Ambient temperature -40 to +50 °C -40 to 122 °F
Weight Approx. 5 g
Model FU-52TZ*1
Optical axis diameter
(Standard target to be detected)
ø1 mm0.039″
Beam emitting direction Top
Fibre unit length 2 m78.74″ free-cut
Fibre unit diameter ø1.3
Minimum bend radius R2 mm0.079″ Tough-Flex
Minimum detectable object Object with a diameter of 0.005 mm0.0002″*2
Environmental resistance Ambient temperature -40 to +50 °C -40 to 122 °F
Weight Approx. 15 g
Model FU-53TZ*1
Optical axis diameter
(Standard target to be detected)
ø0.5 mm0.02″
Beam emitting direction Flat
Fibre unit length 1 m39.37″ free-cut
Fibre unit diameter ø1.0
Minimum bend radius R2 mm0.079″ Tough-Flex
Minimum detectable object Object with a diameter of 0.005 mm0.0002″*2
Environmental resistance Ambient temperature -40 to +50 °C -40 to 122 °F
Weight Approx. 10 g
Model FU-54TZ*1
Optical axis diameter
(Standard target to be detected)
ø1 mm0.039″
Beam emitting direction Flat
Fibre unit length 2 m78.74″ free-cut
Fibre unit diameter ø2.2
Minimum bend radius R2 mm0.079″ Tough-Flex
Minimum detectable object Object with a diameter of 0.005 mm0.0002″*2
Environmental resistance Ambient temperature -40 to +50 °C -40 to 122 °F
Weight Approx. 25 g
Model FU-56TZ*1
Type fibre unit
Shape Thrubeam
Minimum bend radius R2 mm
Minimum detectable object Opaque material with a diameter of 0.005 mm0.0002″ *2
Weight Approx. 20 g
Model FU-57TE*1
Optical axis diameter
(Standard target to be detected)
ø0.7 mm0.028″
Size 6 × 10.5 × 2.5 mm0.236″ × 0.394″ × 0.098″
Fibre unit length 1 m39.37″ free-cut
Fibre unit diameter ø1.0
Minimum bend radius R4 mm0.157″ high-flex
Minimum detectable object Object with a diameter of 0.005 mm0.0002″*2
Weight Approx. 5 g
Model FU-57TZ*1
Optical axis diameter
(Standard target to be detected)
ø0.5 mm0.02″
Beam emitting direction Side
Fibre unit length 1 m39.37″ free-cut
Fibre unit diameter ø1.0
Minimum bend radius R2 mm0.079″ Tough-Flex
Minimum detectable object Object with a diameter of 0.005 mm0.0002″*2
Weight Approx. 5 g
