Model | FU-93 |
Type | Reflective model fiber unit |
Detecting method | Wetted type |
Fibre unit length | 2 m78.74″ free-cut |
Fibre unit diameter | ø1.3×2 |
Minimum bend radius | Fluorocarbon polymer part : R40 mm1.575″*1 fiber part : R25 |
Environmental resistance
Ambient temperature |
-40 to +70 °C -40 to 158 °F |
Weight | Approx. 78 g |
Model | FU-93Z |
Type | Reflective model fiber unit |
Detecting method | Wetted type |
Fibre unit length | 2 m78.74″ free-cut |
Fibre unit diameter | ø1.3×2 |
Minimum bend radius | Fluorocarbon polymer part : R40 mm1.575″*1 fiber part : R0.5 Tough-Flex |
Environmental resistance
Ambient temperature |
-40 to +50 °C -40 to 122 °F |
Weight | Approx. 78 g |
Model | FU-94C |
Type | Reflective model fiber unit |
Fibre unit length | 2 m78.74″ (cannot be cut) |
Minimum bend radius | R40 mm1.575″*1 |
Minimum detectable object | Liquid*2*3 |
Repetition accuracy | 1 mm0.039″ or less (for water) |
Environmental resistance
Pressure resistance |
-49 kPa to 490 kPa |
Ambient temperature | -40 to +200 °C -40 to 392 °F |
Material | Case : fluorocarbon polymer, core fiber : multicomponent glass (inside a fluorocarbon polymer case) |
Weight | Approx. 90 g |
