Model | CZ-H32 | CZ-H35S | CZ-H37S | CZ-H52 | CZ-H72 |
Type | Adjustable spot | Luster cancel | Luster-cancel, small beam spot | Fluorescence detection UV | Luster detection (Adjustable beam spot) |
Detecting area | 50 to 95 mm 1.97″ to 3.74″ (Reco mmended: 70 mm 2.76″) |
28 to 52 mm 1.10″ to 2.05″ (Reco mmended: 40 mm 1.57″) |
11 to 20 mm 0.43″ to 0.79″ (Reco mmended: 15 mm 0.59″) |
25 to 55 mm 0.98″ to 2.17″ (Reco mmended: 35 mm 1.38″) |
15 mm 0.59″ (Center)*3 |
Smallest spot diameter | Small: 3 mm 0.12″dia. Medium: 4.5 mm 0.18″dia. Large: 5.5 mm 0.22″dia. at respective reference distance*1 |
4.5 mm 0.18″dia. at reference distance of 40 mm 1.57″ |
1 mm 0.04″dia. at reference distance of 16 mm 0.63″ |
Approx. 10 mm 0.39 dia. at reference distance of 25 mm 0.98″” | Small: approx. 3 mm 0.12 dia., Large: approx. 5 mm 0.20″ dia. at reference distance of 15 mm 0.59″” |
Light source | Red LED (665 nm)/Green LED (520 nm)/Blue LED (465 nm) | UV (ultraviolet) LED (375 nm) *2 | Red LED (665 nm) | ||
Minimum bend radius of fi ber | 25 mm 0.98″ | 15 mm 0.59″ | ― | 25 mm 0.98″ | |
Receivable wavelength (Receiver) | 425 to 550 nm | ||||
Enclosure rating |
IP40 | ||||
Ambient light | Incandescent lamp: 10,000 lux max., Sunlight: 20,000 lux max. | ||||
Ambient temperature | -10 to +55 °C 14 to 131 °F (No freezing) | ||||
Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z axis | ||||
Material | Housing:Fiberglass reinforced plastic , Lens cover:Polyarylate | Housing:Triacetate, Polyarylate (Metal section: TYPE 304 stainless steel) , Lens cover:Fiberglass reinforced plastic | Housing:Fiberglass reinforced plastic , Lens cover:Glass | ||
Weight | Approx. 40 g | Approx. 45 g | Approx. 40 g | Approx. 50 g |
