Model | PS-25 |
Type | DC type |
Output | NPN |
Sensitivity adjustment | 1-turn trimmer (240°) |
Response time | 1 ms |
Operation mode | LIGHT-ON/DARK-ON (switch-selectable) |
Output Control output | 200 mA (40 V) max. Residual voltage: 1 V max. |
Stability output | |
Protection circuit | ― |
Indicator lamp | Output: Red LED, Stable operation: Green LED |
Timer | ― |
Rating Power voltage | 12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less |
Current/power consumption | 45 mA max. |
Environmental resistance Ambient temperature | -10 to +50 °C 14 to 122 °F (No freezing) |
Relative humidity | 35 to 85 % RH (No condensation) |
Weight | Approx. 50 g |
