Keyence Positioning Sensor SH-822 SH-108

Series#: Keyence Inductive Proximity Sensors

Product Details

Keyence Positioning Sensor SH-822 SH-108
We are First Class Keyence sensor dealer and Keyence sensor distributor in China.
We can Supply all kinds of Keyence sensor parts,such as Keyence Digital Laser Sensors,Keyence Vision Sensors,Keyence Fiber Optic Sensors,Keyence Inductive Proximity Sensors,Keyence Photoelectric Sensors,Keyence Positioning Sensors and So on.
All parts are 100% Original and new in stock by Keyence and fast delivery time within 1 day
100% after sale service and technology Support
MOQ: 1pcs

Qty:

Add to Enquiry Cart

Specification

Download A Munual

Model	SH-416	SH-422^*2	SH-430^*2	SH-440^*2	SH-290^*2	SH-809^*2	SH-816^*2	SH-822^*2	SH-108
Type	Standard Non-shielded Cylindrical & Threaded				Standard Non-shielded Cylindrical	Heat-resistant^*3 Shielded Cylindrical	Heat-resistant^*3 Shielded Threaded	Heat-resistant^*3 Non-shielded Cylindrical & Threaded	Oil-resistant^*4 Shielded Threaded
Shape	ø14.5×20 Cylindrical ＋ Threaded	ø22×35 Cylindrical ＋ Threaded	ø30×45 Cylindrical ＋ Threaded	ø40×55 Cylindrical ＋ Threaded	ø90×30 Cylindrical	ø9.4×18 Cylindrical	M16×20 Threaded	ø22×35 Cylindrical ＋ Threaded	M8×25 Threaded
Detectable object	Ferrous metal (see Characteristics for nonferrous metals)
Standard target (iron, t=1 mm <font color=”#0099ff”>0.04″</font>)	20 x 20 mm 0.79″ x 0.79″^*1	25 x 25 mm 0.98″ x 0.98″^*1	30 x 30 mm 1.18″ x 1.18″^*1	40 x 40 mm 1.57″^*1	150 x 150 mm 5.91″ x 5.91″^*1	15 x 15 mm 0.59″ x 0.59″^*1	20 x 20 mm 0.79″ x 0.79″^*1	30 x 30 mm 1.18″ x 1.18″^*1	10 x 10 mm 0.39″ x 0.39″^*1
Stable detecting range	0 to 6 mm 0.24″	0 to 9 mm 0.35″	0 to 12 mm 0.47″	0 to 18 mm 0.71″	0 to 35 mm 1.38″	0.5 to 2 mm 0.02″ to 0.08″	1 to 4 mm 0.04″ to 0.16″	2 to 8 mm 0.08″ to 0.31″	0 to 2 mm 0.08″
Maximum detecting distance	15 mm 0.59″	22 mm 0.87″	30 mm 1.18″	40 mm 1.57″	70 mm 2.76″	―			3.5 mm 0.14″
Repeatability	0.005 mm 0.0002″^*1	0.008 mm 0.0003″^*1	0.01 mm 0.0004″^*1	0.015 mm 0.0006″^*1	0.03 mm 0.001″^*1	0.002 mm 0.00008″^*1	0.005 mm 0.0002″^*1	0.008 mm 0.0003″^*1	0.002 mm 0.00008″^*1
Hysteresis	0.015 mm 0.0006″^*1	0.02 mm 0.0008″^*1	0.03 mm 0.001″^*1	0.05 mm 0.0002″^*1	0.1 mm 0.004″^*1	0.04 mm 0.002″^*1			0.05 mm 0.002″^*1
Temperature characteristics	0.08%/°C^*1					0.2%/°C^*1
Enclosure rating	IP67					Heat-resistant			Oil-resistant
Ambient temperature	-10 to +60 °C 14 to 140 °F (No freezing)					-10 to +200 °C 14 to 392 °F (No freezing)			-10 to +60 °C 14 to 140 °F (No freezing)
Relative humidity	35 to 85 % RH (No condensation)
Vibration resistance	10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions
Weight	Approx. 73 g	Approx. 195 g	Approx. 225 g	Approx. 280 g	Approx. 650 g	Approx. 55 g	Approx. 83 g	Approx. 170 g	Approx. 45 g
