| Model | EZ-8M | EZ-12M | EZ-18M | EZ-30M | EZ-18T |
| Type | Shielded | ||||
| Shape | M8 | M12 | M18 | M30 | 20 x 32 x 8 mm 0.79″ x 1.26″ x 0.31″ |
| Detecting distance | 1.5 mm 0.06″ ±10% | 2.5 mm 0.10″ ±10% | 5 mm 0.20″ ±10% | 10 mm 0.39″ ±10% | 5 mm 0.20″ ±10% |
| Detectable object | Ferrous metals (see Characteristics for nonferrous metals) | ||||
| Standard target (iron, t=1mm <font color=”#0099ff”>0.04″</font>) |
10 x 10 mm 0.39″ x 0.39″ | 12 x 12 mm 0.47″ x 0.47″ | 18 x 18 mm 0.71″ x 0.71″ | 30 x 30 mm 1.18″ x 1.18″ | 18 x 18 mm 0.71″ x 0.71″ |
| Hysteresis | 10% max. of detecting distance | ||||
| Response frequency | 800 Hz | 600 Hz | 350 Hz | 250 Hz | 350 Hz |
| Operation mode | N.O./N.C. | ||||
| Temperature characteristics | ±10% max. of detecting distance at +23°C 73.4°F, within -25 to +70°C -13 to 158°F | ||||
| Control output | NPN open collector 100 mA max. (40 V max.), Residual voltage: 1 V max. | ||||
| Cable length | 2 m 6.6′ | ||||
| Power voltage | 12 to 24 VDC ±10 %, Ripple (P-P) 10 % or less | ||||
| Current consumption | 13 mA or less | ||||
| Enclosure rating | IP67 | ||||
| Ambient temperature | -25 to +80 °C -13 to 176 °F (No freezing) | ||||
| Relative humidity | 35 to 95 % RH (No condensation) | ||||
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions | ||||
| Shock resistance | 500 m/s2, 3 times in each of the X, Y, and Z directions | 1,000 m/s2, 3 times in each of the X, Y, and Z directions | |||
| Case material | SUS303 | Nickel-plated brass | Aluminium die-cast | ||
| Accessories | Screw nut x 2, toothed washer x 1 |
||||
| Weight | Approx. 50 g | Approx. 65 g | Approx. 130 g | Approx. 235 g | Approx. 55 g |
