| Model | EX-305V*1 | EX-110V*1 | EX-416V*1 | EX-422V*1 | EX-614V*1 |
| Type | Sensor head | ||||
| Amplifier unit | EX-V01(P) | EX-V02(P) | EX-V05(P) | EX-V10(P) | EX-V64(P) |
| Shape | ø5.4 x 18 mm ø0.21″ x 0.71″ Cylindrical | M10 x 18 mm 0.71″ Threaded | ø14.5 x 20 mm ø0.57″ x 0.79″ Cylindrical, threaded | ø22 x 35 mm ø0.87″ x 1.38″ Cylindrical, threaded | 14 x 30 x 4.8 mm 0.55″ x 1.18″ x 0.19″ Thin profile |
| Measuring range | 0 to 1 mm 0.04″ | 0 to 2 mm 0.08″ | 0 to 5 mm 0.20″ | 0 to 10 mm0″ to 0.394″ | 0 to 4 mm 0.16″ |
| Display range | -19,999 to +19,999 | ||||
| Linearity | ±0.3% of F.S. | ||||
| Resolution (No. of averaging measurements: 64) |
0.4 µm 0.02 Mli | 1 µm 0.04 Mil | 2 µm 0.08 Mil | 1 µm 0.04 Mil | |
| Sampling rate | 40,000 samplings max./sec. *2 | ||||
| Display speed | 20 times/sec. | ||||
| Display power | 7-segment 2-color LED | ||||
| Over-range alarm | ±FFFF is displayed. | ||||
| Control output | NPN open-collector or non-voltage contact (Timing input, Reset input, Auto-zero input, Comparator output disable input, Synchronous input, External setting input) | ||||
| Setting method | Upper/lower 2-level setting x 4 patterns (selectable) | ||||
| Signal | ― | ||||
| Response time | 0.075 ms (at maximum speed) | ||||
| OFF-delay time | 60 ms (ON/OFF selectable) | ||||
| Strobe output | NPN: 100 mA max. (40 V max.), Residual voltage: 1 V max. (N.O.) | ||||
| Output voltage | ±5V | ||||
| Impedance | 100 Ω | ||||
| Response time | 0.075 ms (at maximum speed) | ||||
| Temperature characteristics | 0.07% of F.S./°C *3 | ||||
| Major functions | FLL, digital filter, auto zero, offset, calculation, measurement mode (15 types), judgment value memory (4 sets), decimal point shift, display digit changing, display of various errors, etc. | ||||
| Power voltage | 24 VDC ±10 %, Ripple (P-P) 10 % or less | ||||
| Current consumption | 240 mA or less | ||||
| Environmental resistanceAmbient temperature | -10 to +60 °C 14 to 140 °F (No freezing) | ||||
| Relative humidity | 35 to 85 % RH (No condensation) | ||||
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions | ||||
| Weight | Approx. 45 g (including 3-m 9.8′ cable) | Approx. 55 g (including 3-m 9.8′ cable) | Approx. 75 g (including 3-m 9.8′ cable) | Approx. 200 g (including 3-m 9.8′ cable) | Approx. 60 g (including 3-m 9.8′ cable) |
