| Model | IV2-G30F | IV2-G30 |
| Type | Learning/standard type | Standard type |
| Available modes | Learning mode / Standard mode | Standard mode |
| Standard mode built-in tools | Outline, Color area*1, Area*2, Edge pixels, Color average*1, Brightness average*2, Width, Diameter, Edge presence, Pitch, OCR, Color/brightness prohibit, Position adjustment, High-speed position adjustment (1-axis edge/2-axis edge) | |
| Number of tools | Detection tools: 16 tools, position adjustment tool: 1 tool*3 | |
| Switch settings (programs) | 128 programs (when using SD card) / 32 programs (when not using SD card) | |
| Number of storable images | 1000 images *4 | |
| Save conditions | Selectable between NG only, NG and OK near threshold*5, and All *4 | |
| Transfer destination | Selectable between SD card and FTP server | |
| Transfer format | Selectable between bmp, jpeg, iv2p, and txt | |
| Transfer conditions | Selectable between NG only, NG and OK near threshold*5, and All | |
| RUN display | Tools list (Judgment results, degree of similarity, or degree of similarity bar display) *6 | |
| RUN information | Switchable between OFF, histogram, processing time, count, and output monitor Histograms: Histogram, degree of similarity (Max., Min., Ave.), Number of OKs, Number of NGs Processing time: Processing time (latest, Max., Min., Ave.), Image capture interval (latest, Max., Min., Ave.) Count: Trigger numbers, Number of OKs, Number of NGs, Trigger errors, Strobe errors Output monitor: ON/OFF status by output |
|
| Image capture function | Image buffer, Image capture range, Digital zoom (2×, 4×), HDR, High gain, Color filter*1, White balance*1, Brightness correction | |
| Tool functions | Learning mode: Additional learning Standard mode: Mask outline, Masking function, Color extraction/exclusion*1, Color histogram function*1, Monochrome histogram function*2, Scaling function |
Mask outline, Masking function, Color extraction/exclusion*1, Color histogram function*1, Monochrome histogram function*2, Scaling function |
| Utilities | Failing sensor list, Failure hold, Test run, I/O monitor, Security settings, Simulator*7 | |
| Indicators | PWR/ERR, OUT, TRIG, STATUS, LINK/ACT, SD | |
| Input
Type |
Switchable between non-voltage input and voltage input For non-voltage input: ON voltage 2 V or lower, OFF current 0.1 mA or lower, ON current 2 mA (short circuit) For voltage input: Maximum input rating 26.4 V, ON voltage 18 V or higher, OFF current 0.2 mA or lower, ON current 2 mA (for 24 V) |
|
| Number of inputs | 8 (IN1 to IN8) | |
| Function | IN1: External trigger, IN2 to IN8: Enable by assigning optional functions Assignable functions: Program switching, Clear error, External master image registration, SD card save cancel |
|
| Output Type | Open collector output; NPN/PNP switchable, N.O./N.C. switchable For open collector NPN output: Maximum rating of 26.4 V, 50 mA, residual voltage of 1.5 V or less For open collector PNP output: Maximum rating of 26.4 V, 50 mA, residual voltage of 2 V or less |
|
| Number of outputs | 8 (OUT1 to OUT8) | |
| Function | Enable by assigning optional functions Assignable functions: Total judgment (OK/NG), Run, Busy, Ready, Strobe, Position adjustment result, Judgment result of each tool, Result of the logical operation of each tool, Error, SD card error |
|
| Network function | FTP client, SNTP client | |
| Expanded memory | SD card (SD/SDHC) *9 | |
| Material | Main unit case: PC, Power connector: PA/POM, I/O connector: PA, Sensor head connector: Zinc + Ni plating/PA, Ethernet connector: Copper alloy + Ni plating, Main unit rear heat sink: Aluminum, Main unit rear DIN rail fixing tab: POM, Nameplate: PC |
|
| Weight | Approx. 330 g | |
