Pole | Type | In | Model | Catalog No. |
1P+N | B curve | 3A | BKP B3A | 06120302R0 |
6A | BKP B6A | 06120228R0 | ||
10A | BKP B10A | 06120229R0 | ||
16A | BKP B16A | 06120230R0 | ||
20A | BKP B20A | 06120231R0 | ||
25A | BKP B25A | 06120303R0 | ||
32A | BKP B32A | 06120232R0 | ||
C curve | 3A | BKP C3A | 06120307R0 | |
6A | BKP C6A | 06120235R0 | ||
10A | BKP C10A | 06120236R0 | ||
16A | BKP C16A | 06120237R0 | ||
20A | BKP C20A | 06120238R0 | ||
25A | BKP C25A | 06120309R0 | ||
32A | BKP C32A | 06120239R0 | ||
D curve | 3A | BKP D3A | 06120308R0 | |
6A | BKP D6A | 06120242R0 | ||
10A | BKP D10A | 06120243R0 | ||
16A | BKP D16A | 06120244R0 | ||
20A | BKP D20A | 06120245R0 | ||
25A | BKP D25A | 06120311R0 | ||
32A | BKP D32A | 06120246R0 | ||
Standard | Confirming to IEC60898 | |||
Approval | CCC, CQC CB | |||
Protection | Overload and short circuit | |||
Rated current In | 3, 6, 10, 16, 20, 25, 32A | |||
Rated voltage | 230VAC | |||
Breaking capacity | 4.5kA | |||
Characteristic | B, C, D curve | |||
Number of poles | 1P+N | |||
Type of trip | Thermal magnetic release | |||
Type of terminal | Lug type | |||
Terminal capacity | Cables up to 10mm2 | |||
Installation | Mounting on 35mm DIN rail | |||
Width | 17.8mm per pole | |||
Electrical endurance | 20000 cycles |
