Type | BF-a | BF-c |
Rated current | 10~100A | 10~100A |
Breaking capacity, Icu 240V | 10kA | 5kA |
Breaking capacity, Icu 415V | 2.5kA (2, 3pole) | 2.5kA (2, 3pole) |
Rated insulation voltage | 460VAC | |
Number of poles | 1, 2, 3pole | |
Standard | IEC 60947-2 | |
Protection | Overload and short circuit | |
Characteristic | See operating curves (p. 44) | |
Type of trip | Thermal magnetic release | |
Type of terminal | Clamp type | |
Installation | Holder mounting (Bolt on with fixing brackets) | |
Width | 25mm per pole | |
Slot | 50mm | |
Accessory | Not available |
