| Part Number | AJ65SBTB3-16D 24 V DC input module |
| Number of input points | 16 points |
| Insulation method | Photocoupler |
| Rated input voltage | 24 V DC |
| Rated input current | Approx. 7 mA |
| Operating voltage range | 19.2 to 26.4 V DC (ripple ratio: within 5 %) |
| Max. simultaneous ON
input points |
100 % |
| ON voltage/ON current | 14 V or higher/3.5 mA or higher |
| OFF voltage/OFF current | 6 V or lower/1.7 mA or lower |
| Input resistance | Approx. 3.3 kW |
| Common wiring method | 16 points/1 common
(terminal block 3-wire type) |
| Input method | Sink/source shared type |
| Number of stations
occupied |
1 station 32 points assignment (use 16 points) |
| Noise durability | DC type noise voltage 500 Vp-p, noise width 1 ms, noise carrier
frequency 25 to 60 Hz (noise simulator condition) |
| Withstand voltage | 500 V AC for 1 minute between all DC external terminals and
ground |
| Insulation resistance | 10 M W or higher, measured with a 500 V DC insulation resistance
tester |
| Weight (kg) | 0.25 |
| External wiring system | 7-point 2-piece terminal block (transmission circuit, module power
supply terminal), Direct-type 34-point terminal block (I/O power supply area) (M3 screw). |
| Applicable solderless
terminal |
• RAV1.25-3.5 (in conformance with JIS-C2805) [Applicable wire size: 0.3 to1.25 mm2]
• V2-MS3 (Japan Solderless Terminal Mfg. Co., Ltd.), RAP2-3S RAP2-3SL (Japan Terminal Co., Ltd.) 2-3N, 2-3S (NICHIFU TERMINAL INDUSTRIES Co., Ltd.) [Applicable wire size: 1.25 to 2 mm2] |
