Model | CP30-BA | CP30-HU | ||||
Number of poles | 1 | 2 | 3 | 1 | 2 | 3 |
Rated current (A) | 0.1 0.25 0.3 0.5 1 2 3 5 7 10 15 20 30 | 0.1 0.25 0.3 0.5 1 2 3 5 | ||||
Rated short-circuit capacity (kA)
UL 1077 CSA C22.2 No.235 Rated voltage AC (V) |
250 | 250 | ||||
Rated short-circuit capacity (kA)
UL 1077 CSA C22.2 No.235 Rated voltage DC (V) |
65 | 125 | - | 65 | 125 | - |
Rated short-circuit capacity (kA)
UL 1077 CSA C22.2 No.235 AC |
2.5kA at 250V | 2.5kA at 250V | 10kA at 250V | |||
Rated short-circuit capacity (kA)
UL 1077 CSA C22.2 No.235 DC |
2.5kA at 65V | 2.5kA at 125V | - | 10kA at 65V | 10kA at 125V | |
Rated short-circuit capacity (kA) IEC 60934 EN 60934 GB 17701(*3) (Icn) Ui (V) |
250 | 250 | ||||
Rated short-circuit capacity (kA) IEC 60934 EN 60934 GB 17701(*3) (Icn) AC |
2.5kA at 230V | 2.5kA at 230V 10kA at 120V |
10kA at 230V | |||
Rated short-circuit capacity (kA) IEC 60934 EN 60934 GB 17701(*3) (Icn)DC |
2.5kA at 60V | 2.5kA at 120V | - | 10kA at 65V | 10kA at 120V | |
Rated short-circuit capacity (kA) DC | 2.5/2.5kA at 120V | - | 10/10kA at 60V | 10/10kA at 120V | ||
AC/DC common use | common | -(*1) | common | -(*1) | ||
Mode of tripping | Instantaneous type(I); Medium type(M), (MD); Slow type(S), (SD); Fast type(F)(*2) |
Instantaneous type(I); Medium type(M), (MD); Slow type(S) |
||||
Body mounting method | IEC 35mm rail mounting | IEC 35mm rail mounting |
